Used Transformer oil recycling distillation machine-1000L/H

Specifications

Applicable Industries :

Manufacturing Plant, Construction works , Energy & Mining

Showroom Location :

Egypt, Romania, Japan

Condition :

New

Place of Origin :

Henan, China

Brand Name :

YOUHUI

Warranty :

1 Year

Environment :

Waste Management

Usage :

Used oil regeneration device

Machinery :

Oil Purifier

Other Category :

Lubricant

Business Type :

OEM Service Offered

After Warranty Service :

Video technical support, Online support

Local Service Location :

Egypt, Japan, Romania

After-sales Service Provided :

Field installation, commissioning and training

Packaging Details :

standard export packaging

Port :

Lianyungang/Tianjin

Supply Ability :

50 Set/Sets per Year

Price :

$80,000.00 - $300,000.00/Plants

Description

Specifications

vacuum oil recycling for transformer oil
Pumping vacuum and vacuum oiling.
Be able to work with live line on-site.

Usage of oil recycling:

Purify insulating oil and the unqualified transformer oil,the high voltage switch oil,the condenser oil,the mutual inductor oil and so on;

Equipment for pumping vacuum and vacuum oiling of transformer.

Description of oil recycling:

Mainly used in electric power department,industrial and mining enterprises to filter unqualified transformer oil,high voltage switch oil,condenser oil,mutual inductor oil and so on;

Remove deleterious substances moisture,mechanical impurity in oil reliably and rapidly;

Raise flash point and pressure resistance degree of insulating oil;

Be able to work with live line on-site.

Coordinately use with BZ series transformer oil regenerator;

Thoroughly remove biocolloid,free carbon and greasy filth in oil;

Reduce oil's acid content and medium lose.

Tech. Para. Table

`Item	Name of para.		JY-30
Tech. Para.	Nominal Flow	L/min	30
	Working Vacuity	Mpa	-0.098~-0.06
	Working Pressure	Mpa	≤0.5
	TEMP Range	°c	≤80
	Working Power	V/Hz	380/50 3 phase 4 wire
	Heating Power	kW	35
	Working Noise	dB	≤70
	Continuous Working Hours	HR	≥150
	MTBF	HR	≥5000
	Manufacture Standard		The People's Republic of China Machinery Industry Ministry JB/T 5285-2008 The People’s Republic of China Ministry of Power Industry DL/T 521-2004
	Dia of Inlet-Outlet oil pipe	mm	32/32
Index of Oil Treatment	Gas Content	%	≤0.1 (GB/T423)
	Water Content	PPm	≤5 (GB/T7600)
	Impurity	%	No (GB/T511)
	Oil Punture Voltage	KV	45~70 (GB/T507)
	Filtration Rating	µm	≤5

Advantages of oil recycling:

Divide into automatic and manual control.
Automatic foam eliminating installation.
Automatic thermostatic control.
Automatic liquid-level control.
Filtrating online(be able to operate without person).
Phase sequence and lack of phase protective function.
The trinity protective function.
Pollution degree of oil purifier comparator function.
Sudden stoppage safety control function.
Low energy consume,saving running cost,wide mean time between maintenance.

Attached Documents:

Instruction manual of oil purifier.
Electric appliance schematic of oil purifier.
Instruction manual of vacuum pump.
Instruction manual of oil pump.
Instruction manual of ericomp.

Comparasion picture of the waste oil and the regenerated oil:

The black one is the used engine oil,and the red one is regenerated by our machine,and the light yellow is refined after the used engine oil wasregenerated.

Used Transformer oil recycling distillation machine-1000L/H

Complete Plant Includes:

1. Vacuum system

2. Thermal oil heating system

3. Electric control cabinet

4. Technical personnel training

5. Technical training and so on.

Through survey and investigation, the equipment our company developed is originated in our country.

We have received national invention patents.

The number of invention patent is 200810141346.8

Utility model patent No.:ZL20082014967303

This equipment has been recommended as the first energy-saving products by Luoyang Municipal Government and good for popularization..

Simlar Projects:

Used Transformer oil recycling distillation machine-1000L/H

Detail Show :

Used Transformer oil recycling distillation machine-1000L/H
