CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
Specifications
Brand Name :
CABLEFORCE
Model Number :
MC08C4LSXSB26CG30C6A
Certification :
UL Certified, CUL Certified, CE/ EMC, IP67, IP69K
Place of Origin :
Guangdong, China
MOQ :
100
Price :
Negotiated
Payment Terms :
T/T
Supply Ability :
60000 pcs/month
Delivery Time :
2~3 weeks
Packaging Details :
Our standard packing: Individual part with transparent PE bag with label, OEM packing available.
Coding :
X Coding
Reference Standard :
IEC 61076-2-109
Gender :
Female to RJ45
Cable Specification :
AWG26 CAT 6A
Termination :
M12: Soldering, RJ45: Piercing
Application :
Profinet Ethernet
Characteristic impedance :
100Ω ±15
Over-molding :
TPU
Description
M12 Safety Light Grids Curtains Industrial Ethernet Cable Female To RJ45 CAT 6A
Connector Technical Data
Model Number MC08C4LSXSB26CG30C6A
Contact No 8 pin
Coding
X code
Contact Resistance ≤5mΩ
Characteristic Impedance
100Ω ±15
Wire Gauge
0.14mm²(AWG 26) CAT 6A
Type
Profinet Industrial Ethernet Cable
Contact Carrier
TPU+GF
Screw Nut
Brass CNC Nickel plated
Contact
 Phosphor bronze
Protection Degree
IP67,IP68
Description

Manufacturing environments, where PROFINET is most commonly used, are characterized by having challenging environmental conditions. In that environment, standard Ethernet cables, like those you find in your office or home, might break or damage easily. Extreme temperatures, moisture, vibrations, electro magnetic interference, and many other factors contribute to the deterioration of cables.

Due to the challenging environment meant, industrial Ethernet cables are a common choice in automation facilities. On the wire, Industrial Ethernet is just Ethernet. Yet, Industrial Ethernet is characterized by rugged hardware, and its wiring is protected with shielding and jacketing.

CABLEFORCE Products Features

● IP65 IP67 IP68 and UL approvals

● 8P poles are available

● TPU over molded and PA+GF or metal shell
● Anti vibrating locking screw desigh
● Operating voltage: 630V, 250V, 60V, 48V, 30V

● Current rating: 20A, 16A, 12A, 8A, 4A, 2A, 1.5A

FAQ

● What are the advantages of PROFINET?

PROFINET offers the option for wireless transmission over WiFi and Bluetooth. Using standard Ethernet components such as switches, cables, or connectors in PROFINET networks is advantageous. Utilizing Ethernet cables in PROFINET projects is a huge benefit, as they are ubiquitous, affordable, and versatile.

● What is difference between PROFIBUS and Ethernet?

PROFINET is a fieldbus system which is based on Ethernet. PROFINET is one of the many industrial ethernet systems out there, which is often compared to PROFIBUS. PROFINET is a full duplex system. Because it's ethernet based, PROFINET can operate on a much higher transmission speed than PROFIBUS.

●Do I need PROFINET If I already have Ethernet?

On the wire, they are the same thing. Yet, industrial Ethernet is characterized by ruggedized hardware, shielding protection, and proper jacketing. Do I need PROFINET if I already have Ethernet in an automation network? Yes, you still need PROFINET. You create a connection if you link two nodes in a network with an Ethernet cable.

CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids

CAT 6A Industrial Ethernet Cable M12 Female To Rj45 Cable For Safety Light Grids
