Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine
Specifications
Brand Name :
STETON
Model Number :
S280
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
10 UNITS PER MONTH
Packaging Details :
N/A
Engine power :
132 KW
Pullback force :
280KN
Rotation :
10000N.M
Mud Pump :
280L
Description

Low Failure Rate Horizontal Directional Drilling Machine S280 28Ton horizontal directional drilling machine​
I KEY point:

Mini machine Body;

Fast travelling and tracking speed;

Powerfull.

II Features:

Equipped with Cummins 132kw engine, large power, stable performance, lower fuel consumption, lower noise, more suitable working in city area.
Power head thrust and rotation adopts cycloid motor from Eaton, with large torsion, stable performance. Rotation have two speed , drilling faster and more torque; Thrust have 3 speed, let the work finished more faster.
American style surface, looks so powerful.
Simple electric circuit design, low failure rate, convenient maintenance.
Equipped with φ60×3000mm drill rods moderate machine size adapts to narrow and small working area and high efficient construction as well.
Mud flow control system, can depends customer project save water.
Auto anchoring system can be choose separate.


III Specifications:

Engine PowerKW132/2200
Max Thrust forceKN280
Max Pullback forceKN280
Max TorqueN.M10000
Max Rotary speedRpm120
Max carriage speedm/min35
Max Mud pump flowL/min280
Max Mud pressureMpa8±0.5
Main machine sizemm6100x1800x1700
WeightT10
Diameter of drilling rodmmφ73
Length of drilling rodm3
Max diameter of pullback pipemmφ150 - φ700
Max construction lengthm300
Incidence Angle°10～22
Climbing angle°14
