Diesel Engine Driven Horizontal Hdd Drilling Equipment For Narrow Space Pipe Laying
Diesel Engine Driven Horizontal Hdd Drilling Equipment For Narrow Space Pipe Laying
Specifications
Brand Name :
STETON
Model Number :
S350
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Supply Ability :
10 UNITS PER MONTH
Packaging Details :
N/A
Engine power :
153 KW
Pullback force :
3500KN
Rotation :
13000N.M
Mud Pump :
320L
Description

Horizontal Directional Drilling Machine - S350 For narrow space Pipe laying

I KEY point:

Mini machine Body;

Fast travelling and tracking speed;

Powerfull.

II Features:

Equipped with Cummins 153kw engine, large power, stable performance, lower fuel consumption, lower noise, more suitable working in city area.
Power head thrust and rotation adopts cycloid motor from Eaton, with large torsion, stable performance. Rotation have two speed , drilling faster and more torque; Thrust have 3 speed, let the work finished more faster.
American style surface, looks so powerful.
Simple electric circuit design, low failure rate, convenient maintenance.
Equipped with φ73×3000mm drill rods moderate machine size adapts to narrow and small working area and high efficient construction as well.
Mud flow control system, can depends customer project save water.
Auto anchoring system can be choose separate.

III Specifications:

Engine Power KW 153/2200
Max Thrust force KN 350
Max Pullback force KN 350
Max Torque N.M 13000
Max Rotary speed Rpm 120
Max carriage speed m/min 35
Max Mud pump flow L/min 320
Max Mud pressure Mpa 8±0.5
Main machine size mm 6800x2200x1700
Weight T 12
Diameter of drilling rod mm φ73
Length of drilling rod m 3
Max diameter of pullback pipe mm φ150 - φ700
Max construction length m 300
Incidence Angle ° 10～22
Climbing angle ° 14
