YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
YD41 series Single column hydraulic press 1Ton-250 Ton, Dali hydraulic factory, famous brand
Specifications
Brand Name :
DALI
Model Number :
YD41
Certification :
ISO9001
Place of Origin :
Wuxi, China
MOQ :
1set
Price :
USD2000--35000 per set
Payment Terms :
T/T
Supply Ability :
99set 1month
Delivery Time :
1month
Packaging Details :
plywood case
Hydraulic :
Press machine
Description

DALI Hydraulic Press machine factory. Famous brand, 30 years of manufacturer

Contact: 0086 158 52708933 Min Chen

E-mail: chenminmin80@hotmail.com

Factroy website: www.dlyyjx.cn/en/

YD41 series hydraulic press is widely used in machinery industry. It is widely used to straighten, to form, to press , to bend, to stretch all kinds of shaft parts, forming parts, sleeve parts etc. It can be built in customer's automatic assembly line. DALI factory welcomes you. Our state-of-the-art technology will fully meet your special working requirements.

The factory supplies non-standard design and manufacturing based on customer‘s special requirements.

Type Unit 1T 1.6T 2.5T 4T 6.3T 10T 16T 25T 40T 63T 100T 160T 250T
Nominal pressure KN 10 16 25 40 63 100 160 250 400 630 1000 1600 2500
Hydraulic Max. working pressure MPa 5.5 5.1 5.5 5.6 6.28 8.1 13 20.3 22.6 16.5 26.5 25 25
Max. distance between slide endface and worktable mm 300 300 350 390 400 500 500 550 600 630 800 1000 1000
Slide Max. stroke mm 120 160 160 200 250 300 350 350 400 500 500 500 500
Slide down speed mm/s 60 45 50 50 50 50 50 50 50 50 36 24 23
Slide withdraw speed mm/s 82 90 110 110 0 100 115 115 110 98 98 65 65
Throat depth mm 110 160 160 180 200 250 300 300 320 350 350 325 360
Working table dimension front, back mm 250 320 320 320 400 430 500 500 550 650 650 650 660
left, right mm 300 480 480 480 500 550 600 600 700 700 800 800 800
Distance between worktable and ground mm table sytle 700 700 710 700 700 710 710 650 650 730 750 710
Blanking hole diameter mm 　 70 70 70 80 80 100 100 100 140 140 200 200
oil pump name oil pump name oil pump name
Electric motor output kw 1.1 1.5 1.5 1.5 2.2 4 4 4 5.5 7.5 8.5 11 15
Machine overall dimension front,back mm 530 680 725 785 800 950 1100 1100 1200 1550 1650 1340 1767
left, right mm 500 650 380 400 500 500 650 680 700 1000 1600 2000 2000
height above ground mm 1455 1450 1600 1630 1650 1800 1900 2200 2500 2500 2500 2950 3305
Total weight(approx.) kg 250 500 500 500 1000 1200 1500 2000 2500 4000 5000 6500

8000
