Specifications
Brand Name :
Sanhui
Model Number :
Customized
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 Kilograms
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500 Kilograms per Month
Delivery Time :
20 days after order
Packaging Details :
plywood case
Application :
balance weight, Military industry, Balance weight, Military industry
Material :
Pure tungsten/alloy
Tensile :
3500-4000
Roughness :
Ra1.0
Hardness :
20HRC
Conditions :
Vacuum annealed or un-annealed
Description

High Density Tungsten Heavy Alloy WNiFe/WNiCu Plate With Density of 16.8-18.8g/cm3

Introduction of Tungsten Heavy Alloy

Tungsten based high specific gravity alloys are also known as high-density tungsten based metals or high specific gravity tungsten alloys which is an alloy material based on tungsten (tungsten content is generally 80% ~ 98%) and composed of a small amount of Ni, Fe, Cu, Co, Mo, Cr and other elements,

There are two kinds of tungsten heavy alloys: tungsten nickel iron alloy (weak magnetic) and tungsten nickel copper alloy (non-magnetic).

Properties of WNiFe Tungsten Heavy Alloy

Tungsten heavy alloy, WNiFe alloy is characterized by high strength, high hardness, good conductivity and thermal conductivity, low thermal expansion coefficient, corrosion resistance and oxidation resistance, good machinability and weldability, and have a series of excellent physical properties and usability performance. In addition, tungsten heavy alloy, tungsten nickel iron has excellent absorption capacity for y-ray or X-ray.

Applications of WNiFe Tungsten Heavy Alloy

Tungsten nickel iron alloy is widely used and has become the main tungsten based heavy alloy with large consumption. As general applications, such as counterweights, radiation shielding devices, etc., sintered WNiFe alloys are directly used; However, for applications requiring high mechanical properties, the WNiFe alloy just needs deformation processing and heat treatment to achieve strengthening.

Tungsten Heavy Alloy Specification:

class Tungsten weight% Density g/cc Hardness MAX
1 90 16.85-17.25 32
2 93 17.15-17.85 33
3 95 17.75-18.35 34
4 97 18.25-18.85 35

The density of tungsten heavy alloy is very high. Its density is twice of steel. Tungsten heavy alloy has low thermal coefficient but it has high absorption ability and high-energy rays. The tungsten heavy alloy we make conforms to ASTM B777-99 standard.

It is massively applied to balancing weight mould and high temperature moulds. Also they can be made into protective shield and high-energy rays. The tungsten heavy alloy conforms to ASTM B 777-99 standard.

High Density Tungsten Heavy Alloy WNiFe / WNiCu Plate With Density Of 16.8 - 18.8g/Cm3

High Density Tungsten Heavy Alloy WNiFe / WNiCu Plate With Density Of 16.8 - 18.8g/Cm3

High Density Tungsten Heavy Alloy WNiFe / WNiCu Plate With Density Of 16.8 - 18.8g/Cm3
