Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
Specifications
Brand Name :
Sanhui
Model Number :
WNiFe/WNiCu
Certification :
ISO 9001:2008
Place of Origin :
Henan, China
MOQ :
10 kgs
Price :
USD 60-100 per kg
Payment Terms :
D/A, D/P, T/T, Western Union
Supply Ability :
500kgs per month
Delivery Time :
15-20 days
Packaging Details :
plywood case
Name :
Tungsten Heavy Alloy Plate
Dimensions :
1.0-10mm
Grain Size :
0.6-0.8 micro
Application :
balance weight, Military industry
Roughness :
Ra1.0
Conditions :
Vacuum annealed or un-annealed
Elongation :
5-22%
Tensile Strength :
780-980 Mpa
Density :
17.5-18.1 g/cm3
HRC :
28-32
Description

Radiation protection Max as 18.8g/cm3 Tungsten Heavy Alloy WNiFe Parts in Medical Field

Material Property

Tungsten Nickel Iron alloys (~18.8g/cm3) are made of tungsten based two phase composites with Ni, Fe as additions to form a ductile matrix. Tungsten Nickel Iron alloys has good machining properties, excellent radiation resistance, lower expansion coefficient, high strength and modulus of elasticity, which make them extensively used in radiation protection and guidance, balance weights, security and defense etc.

Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field

Tungsten Nickel Iron Alloy Property

− High Density:Max as 18.8 g/cm3

− High Strength:Tensile strength as 700-1000 MPa.

− Excellent Radiation Protection:Tungsten alloy is 1.7 times than Lead in radiation protection capability with same thickness.

− The Coefficient of Thermal Conductivity: The thermal conductivity coefficient of tungsten alloy is 5 times of die steel.

− Small Thermal Expansion Coefficient: Tungsten thermal expansion coefficient is 4~6×10-6/℃, only iron or steel 1/2-1/3.

− Good Plasticity, Machining and Welding Capability.

− Compared with lead toxicity, tungsten alloy is zero damage of environment. Radiation detectors made by tungsten alloy has no harm to human body.

− Compared with tungsten nickel copper alloy, tungsten nickel iron alloy has ferromagnetic property, and the mechanical properties, processing properties are better than tungsten copper nickel alloy.

Application

Radiation protection and guidance: because of its high density (~18.8 g / cm3), and excellent X-ray, gamma ray absorptive capacity, excellent process ability, making Tungsten Nickel Iron alloy become ideal material for radiation therapy collimator and protection components.

Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field

Product Specification

Normal Tungsten Nickel Iron Alloy Property

Grade

Chemical Component%

Density

(g/cm3)

Tensile Strength(MPa)

Yield Strength(MPa)

Elongation

(%)

HRC Max

(HRC)

Magnetic
W Component NiFe
ATM1700 90 Remain 16.85-17.25 ≥758 ≥517 ≥5 32 Yes
ATM1750 92.5 Remain 17.15-17.85 ≥758 ≥517 ≥5 33 yes
ATM1800 95 Remain 17.75-18.35 ≥724 ≥517 ≥3 34 yes
ATM1850 97 Remain 18.25-18.85 ≥689 ≥517 ≥2 35 yes

High performance sintering tungsten Nickel iron alloy property

Grade

Density
(g/cm3)

Tensile Strength
(MPa)

Yield Strength
Rp0.2(MPa)

Elongation
A(%)

(%)

Hardness

(HRC)

Magnetic
ATM1700 16.85-17.25 900 600 15 ≤32 yes
ATM1750 17.15-17.85 900 600 15 ≤33 yes
ATM1800 17.75-18.35 850 600 10 ≤34 yes
ATM1850 18.25-18.85 800 600 7 ≤35 yes

Radiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical FieldRadiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical FieldRadiation Protection 18.8g/Cm3 Tungsten Heavy Alloy W95-97NiFe Parts In Medical Field
