Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts
Specifications
Brand Name :
oem
Certification :
ISO9001:2008/SGS/ROHS
Place of Origin :
china
MOQ :
1 qty
Price :
dollar 2-6
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 per/month
Delivery Time :
5-8 working day
Packaging Details :
wooden box
Application :
Industrial Ceramic,Structure Ceramic,thermocouple protection tube,Wear resistant,Knitting Spare Part
Material :
Zirconia Ceramic
Features :
Heat resistance / Wear resistance / High purity / Refractory / High Corrosion / Good Insulation...
Shape :
square,oval,rectangular,Round Cylindrical
Tolerance :
±0.05mm,can be polished,As customer's drawing
Usage :
Wear-resisting Material,Industry Usage,Structural parts for machinery,Indutry equipment
Description

Zirconia washer Parts High strength hard insulating customized Zirconia Ceramic Pats gasket,ring,spacer

Zirconium dioxide ZrO2, sometimes known as zirconia, not to be confused with zircon, is a white crystalline oxide of zirconium. Its most naturally occurring form, with a monoclinic crystalline structure, is the rare mineral baddeleyite. The high temperature cubic crystalline form is rarely found in nature as mineral tazheranite ; (Zr,Ti,Ca)O2 and a doubtful mineral arkelite. This form, also called cubic zirconia, is synthesized in various colours for use as a gemstone and a diamond simulant.

zppd_Company_Profile-_Dongguan_Mingrui_Ceramic_1-a...

Us a ceramic washer manufacturer, us produce multi type ceramic washer, spacer, gakset by our cusotmer requirements.

Hard Insulating Gasket Ring Spacer Zirconia Ceramic Parts

ZrO2 Zirconia characteristics

  • High fracture toughness
  • Thermal expansion similar to cast iron
  • Extremely high bending strength and tensile strength
  • High resistance to wear and to corrosion
  • Low thermal conductivity
  • Oxygen ion conductivity
  • Very good tribological properties

Data Sheet↓

Item Unit Typical Values
Physical Properties
Color Customized
Density g/cm3 6.0
Zirconia Content % 94.4%
Gas permeability 0
Water Absorption 0
Crystal Size um 0.5
Mechanical Properties
Rockwell Hardness(45N) R45N 78
Vickers Hardness (Load 500g) Gpa(Kg/mm²) 11.5(1175)
Flexural Strength(20°C) Mpa 800
Compressive Strength(20°C) Mpa 2000
Modulus of Elasticity(20°C) Gpa >200
Fracture Toughness(20°C) MPam1/2 9.0
Thermal Properties
Thermal Conductivity(20°C-400°C) W(m.K) 2.5
Thermal Expansion Coefficient 10-6/°C 9.6
Thermal Shock Resistance T°C 250

Application industry:

Machinery, fiber optic, knife, medical, food, petroleum etc.

Products made from Zirconium Oxide (ZrO2):

Advanced Ceramic Tubes

Bearing Technology in Automotive Engineering

Compressors, Components for

Cutters

Drawing Tools

Forming Applications

Pumps, Components for

Seal Rings, Bearings and Sealing

Sealing Technology (Seal Rings, Bearings)

Technical Cutters

Tubes and Pipes

Valves, Components for

Wire Drawing, Components for

Zirconium Oxide-stabilized Substrates

We can supply the products according to customer's drawings, samples and performance requirement.

Do not find similar ceramic products on this page?

For more detail of ceramic products like price,shipping,samples...

Quick Free Quote . Our official E-mail: admin@cerampart.com(Mr admin).thanks

Hard Insulating Gasket Ring Spacer Zirconia Ceramic PartsHard Insulating Gasket Ring Spacer Zirconia Ceramic PartsHard Insulating Gasket Ring Spacer Zirconia Ceramic PartsHard Insulating Gasket Ring Spacer Zirconia Ceramic Parts

Delivery:
Custom OEM will be shipped within 15 days after determining the parameters
The samples will be shipped within 3 days
Quick Delivery Via Fedex,DHL,UPS,TNT Etc.
Support customer to designate shipping company
For more informations (the price,delivery time,moq etc)about the ceramic plates, please contact us or email:admin@cerampart.com


CEO: Admin deng
Dongguan Mingrui Ceramic Tech. Co. Ltd.
Add: No.21 Chuangxing Rd., 2nd Industrial Zone of Shangsha,
Chang'an town, Dongguan city, Guangdong, China 523867
Email: admin@cerampart.com

FAQ
1. Monthly Capacity: 50,000-60,000 pcs;
2. Material: OEM or as per your suggestion;
3. Lead time: about 7-20 days, pls confirm the quantities required;
4. Incoterm: FOB, CFR, CIF;
5. Delivery Cost: It is determinated by the destination port;
6. Payment Term: PayPal; T/T; L/C.
7. Shipment: by sea, by air, by courier, by post, etc.
