Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate
Specifications
Brand Name :
OEM
Model Number :
0005
Certification :
SGS TUV ROHS
Place of Origin :
CHINA
MOQ :
2pcs
Price :
USD0.5-20/PCS
Payment Terms :
T/T, Western Union
Supply Ability :
1000PCS/Month
Delivery Time :
20-30 days
Packaging Details :
Normal box
Material :
Alumina
MOQ :
1-2pcs
Color :
White or Ivory
Sizes :
Customized
Package :
Normal
Description

AL2O3 Alumina Ceramic Plate Ceramic Insulation Thermal Pads Alumina Oxide Ceramic Plate

Alumina oxide ceramic plate has a high thermal conductivity : 24w/m.k,

0.635mm, 1.0mm, 2.0mm, 3.0mm, 4.0mm can be offered for TO-220, TO-247, TO-264, TO-3P sizes, customized size is available, ROHS is compliant.

IC, MOS, transistor, schottky, IGBT, high density switch power supply, HF communications equipment and brazing machine.

Test Item Unit 96% Aluminum Oxide
Density g/cm³ 3.90
Water Absorption % 0
Thermal Expansion Coefficient 10-6/K 8.5
Young's Modulus GPa 340
Poisson Ratio - 0.22
Hardness(Hv) MPa 1650
Bending Strength (room temperature) MPa 310
Bending Strength (700°C) MPa 230
Compression Strength (room temperature) MPa 2200
Fracture Toughness MPa'm½ 4.2
Thermal Conductivity (room temperature) W/m·K 24
Insulation Strength KV/mm 10
Long-term Working Temperature ℃ 1480
Ratio Resistivity Ω·mm²/m >1016
Maximum Service Temperature (no-load) ℃ 1750
Acid-base and Corrosion Resistance - Strong
Refractoriness ℃ 2000
Standard Size

TO-220: 18.5mm*12mm / 20mm*14mm ; TO-247: 22mm*17mm

TO-3P: 25mm*20mm ; TO-264: 28mm*22mm

With or without hole available ; Customized size available.

Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate

Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate

Ceramic Insulation Thermal Pads 4mm Alumina Oxide Ceramic Plate

Application industry: Machinery, fiber optic, knife, medical, food, petroleum etc.
Specific application: plunger, ceramic shaft, fiber optic bushing, stub, grinding, ceramic knife, ceramic slide guide, machined plunger, mobile phone shell, watch case, haircut razor blade etc.
