Specifications
Brand Name :
Macy
Model Number :
UV-1700PC
Certification :
CE
Place of Origin :
China
MOQ :
1pcs
Price :
USD2200/Set
Payment Terms :
Western Union, MoneyGram, T/T, L/C
Supply Ability :
50000Set / month
Delivery Time :
5-8days
Packaging Details :
Carton Box
Name :
UV-V Spectrophotometer
key words :
UV-V Spectrophotometer wide wavelength
Wavelength Range :
190~1100nm
Band Width :
1.8nm
Wavelength Accuracy :
±0.3nm
Photometric Accuracy :
±0.3% τ(0-100%τ) ±0.002A(0~0.5A) ±0.003A(0.5A~1A)
Photometric Repeatability :
±0.15% τ(0-100%τ) ±0.001A(0~0.5A) ±0.0015A(0.5A~1A)
Stray light :
≤0.03% τ (220nm NaI,340nm NaNO2)
Stability :
0.0005A/h@500nm
Wavelength Setting :
Automatic
Photometric Display Range :
-4~4A
Detector :
Import silicon Photodiode
Power Requirement :
AC220V/550Hz 110V/60Hz
Power :
120W
Description

UV-1700PC UV-V Spectrophotometer

UV-1700PC successful implementation of the stringent requirements of high accuracy and reliability measurement to meet the requirements of various applications that can be used in biological research, bio-industry , pharmaceutical analysis , pharmaceutical, teaching and research, environmental protection , food hygiene, clinical examination , health and epidemic prevention , and other fields .


Spectrometer

Optical System Double beam
Wavelength Range 190~1100nm
Band Width 1.8nm
Wavelength Accuracy ±0.3nm
Wavelength Repeatability ≤0.1nm
Photometric Accuracy ±0.3% τ(0-100%τ) ±0.002A(0~0.5A) ±0.003A(0.5A~1A)
Photometric Repeatability ±0.15% τ(0-100%τ) ±0.001A(0~0.5A) ±0.0015A(0.5A~1A)
Stray Light ≤0.03% τ (220nm NaI,340nm NaNO2)
Stability 0.0005A/h@500nm
Noise ± 0.0002A @500nm
Baseline Flatness ± 0.001A
Photometric Mode T,A,C,E
Wavelength Setting Automatic
Photometric Display Range -4~4A
Display Mode 6 inches high brightness blue LCD
Detector Import Silicon Photodiode
Light Source Import Deuterium Lamp & Tungsten Halogen Lamp
Power Requirement AC 220V/50Hz 110V/60Hz
Power 120W
Dimensions(W*D*H) 560*450*230mm
Weight 28Kg

Competitive Advantage:

1.A wide wavelength range, the wavelength range to meet the various requirements of the field
2.Automatic design to achieve the most simple means of measurement
3.LSI design greatly improves the stability and reliability of the system
4.Improved optimization of the optical design , import source and receiver system created a high performance and high reliability
5.Rich measurement methods , with a wavelength scan , time scan , multi-wavelength determination , multi-order derivative determination (optional ) , dual-wavelength , three-wavelength (optional ) DNA protein measurements (optional ) , and other measurement methods to meet different measurement requirements , and can be displayed directly on a 6- inch screen
6.Based on user requirements optional hole rack , manual four with stand , manual Eighth rack , automatic Eighth frame, glass stand , test tube rack , 1cm colorimetric frame , 5cm colorimetric frame , 10cm colorimetric racks
7.Measurement data can be output through the printer with USB interface
8.Can be powered down to save the measurement parameters and data , user-friendly
9.Can achieve more accurate and flexible measurement via PC control , which can meet the needs of different users

1.8nm Wide Wavelength Range Uv Visible Spectrophotometer Double Beam Automatic Design

1.8nm Wide Wavelength Range Uv Visible Spectrophotometer Double Beam Automatic Design


Application Field 1.8nm Wide Wavelength Range Uv Visible Spectrophotometer Double Beam Automatic Design

Certificate 1.8nm Wide Wavelength Range Uv Visible Spectrophotometer Double Beam Automatic Design

Company profile

Macy(China) Instruments Inc is part of Shanghai Macylab Instrument Inc, is a high-tech enterprise with independent intellectual property rights . Macy hold the pioneering concept "technology - because you change " , and as a business purpose, and constantly explore, bold innovation. Especially in the field of analytical instruments ,Macy constantly develop advanced products that enable Macy to become a high-quality instrument resource supplier and leader.

1.8nm Wide Wavelength Range Uv Visible Spectrophotometer Double Beam Automatic Design

Macy's headquarter and production base is located in Shanghai, the marketing center in Beijing, and three R & D bases in Jiangsu, Shanghai, and Shandong. To take full advantage of the country's intellectual resources, MACY and the domestic and foreign research unit also conducted deep scientific research cooperation, will continue to put the research achievements into productivity .To better serve our customers, Macy has 12 domestic offices, tailored to meet the needs of your application solutions to improve the value of the products. At the same time continue to serve domestic users, Macy also with distribution in over 20 countries to establish a deep strategic partnership cooperation.
Along with Macy accelerate the pace and rank among the global brand instruments, Macy increasing demands of our own, and we also hope to get the care and support of the community, Let us work and outlook together.Technology, will change because you and us.
