Industrial Furnaces Alumina Silica Refractory Brick
Industrial Furnaces Alumina Silica Refractory Brick
Industrial Furnaces Alumina Silica Refractory Brick
Industrial Furnaces Alumina Silica Refractory Brick
Industrial Furnaces Alumina Silica Refractory Brick
Industrial Furnaces Alumina Silica Refractory Brick
Specifications
Brand Name :
CRE
Model Number :
XCL
Certification :
ISO9001, ISO14001,ISO50001,ISO45001
Place of Origin :
JIANGSU,CHINA
MOQ :
1*20GP
Price :
FOB Shanghai USD150-1500/MT
Payment Terms :
L/C, T/T
Supply Ability :
10.000MT Per month
Delivery Time :
To be negotiated
Packaging Details :
1.On wooden pallets with plastic cover 2. According to customer's demands for Customized Processing Fused Semi-rebonded Magnesia Chrome Bricks
Apparent Porosity % :
22-24
Refractoriness Under Load :
1790
Standard Size :
230X114X65
Application :
Cement rotary kiln,glass kiln regenerative chamber etc
Color :
Black and green
Processing :
Bending, Welding, Punching, Decoiling, Cutting, Moulding
Cold crushing strength :
50-55 Mpa
product name :
Alumina Silica Refractory Brick
Description

Industrial Furnaces High Alumina Silica Refractory Bricks

The series of bricks contain Al2O3 content is 30%-48%,SiO2 content is 50%-65%,and a small number of alkali metals,alkaline earthmetal oxides TiO2,Fe2O3 etc.Made by flint clay clinker and binder,through Crushing,Mixing,Shaping,Drying and high temperature Sintering.

Its feature is excellent physical and chemical properties in high temperature,low thermal conductivity and low impurity.It widely used in variety of furnace lining as Reheating Furnace,Blast furnace,Coke Oven,etc.

Key Feature of Insulating Fire Brick

* Low iron content

* Resistance to thermal shock

* Low density

* Low heat storage

* High insulating properties

* Energy saving


Application of Insulating Fire Brick

* Primary hot face linings

* Back-up insulation for furnaces and kilns

* Flue insulation
* Sulphur recovery equipment .
* Hot blast stoves

* Cracking Furnace

* Ceramic Industry

* Continuous and batch kilns

* Power Generation

* Boiler insulation etc …

Industrial Furnaces Alumina Silica Refractory BrickIndustrial Furnaces Alumina Silica Refractory Brick

Index
Item/Grade High Alumina Refractory Brick
SK-36 SK-37 SK-38 SK-40
Al2o3% (≥) 55 65 70 82
Fe2o3% (≤) 2.0 2.0 2.0 2.0
Refractoriness (SK) 36 37 38 40

Refractoriness under load,

0.2MPa, ℃ (≥)

 1450 1480 1530 1600
Porosity(%) 20-23 20-23 20-22 18-20
Density(g/cm3) 2.25-2.4 2.3-2.5 2.4-2.6 2.5-2.7
Cold crushing strength, MPa (≥) 45 50 60 70

Certificates

Industrial Furnaces Alumina Silica Refractory Brick

  • ISO9001
  • ISO14001
  • ISO50001
  • ISO45001
  • Relevant patent certificates

Wooden pallets with plastic film or according to yours
1. Strong packing protects the goods from any possible damage during transit.
2. Solid packing and overall stuffing prevent the cases from vibration and jarring.
3. Necessary precaution is taken to protect goods from pilferage or rain.

Every possible precaution is taken to ensure our products in prime condition when reach customers around the world.

Industrial Furnaces Alumina Silica Refractory BrickIndustrial Furnaces Alumina Silica Refractory Brick
