0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
Specifications
Brand Name :
JN
Model Number :
JN-CO-2
Place of Origin :
CHINA
Certification :
ISO9001
MOQ :
500PCS
Price :
Negotiable
Packaging Details :
By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time :
25 Days
Payment Terms :
L/C,T/T
Supply Ability :
500K PCS/Month
Curie Temperature :
700-800°C
Property :
Isotropic And Anisotropic Is Avaible
Tolerance :
0.1mm
Applications :
Motors, Sensors, Magnetic Couplings, Magnetic Separators, Etc.
Color :
Brown, Black
Magnetization :
Multipolar Or So
Demagnetization Resistance :
Excellent
Advantages :
High Temperature Stability, High Magnetic Strength, Corrosion Resistance
Description

0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice for Magnetic Separators

JN's SmCo Magnets have a wide range of applications and are suitable for various scenarios, thanks to their unique properties and shape options. Some of the common applications and scenarios for our SmCo Magnets include:
Bar SmCo Magnet - Ideal for use in motors, generators, and loudspeakers.
Disc SmCo Magnet - Perfect for sensors, magnetic couplings, and magnetic bearings.
Cylinder SmCo Magnet - Suitable for aerospace and military equipment.
Ring SmCo Magnet - Used in MRI machines, magnetic separators, and magnetic chucks.
Arc SmCo Magnet - Great for high-speed motors, magnetic pumps, and magnetic couplings.
Segment SmCo Magnet - Commonly used in magnetic levitation systems, magnetic switches, and magnetic clamps.
No matter what your industry or specific application may be, JN's SmCo Magnets can provide the high performance you need.
Technical Parameters:
Advantages High Temperature Stability, High Magnetic Strength, Corrosion Resistance
Curie Temperature 700-800°C
Magnetic Properties High Magnetic Energy Product, High Coercive Force, High Remanence
Demagnetization Resistance Excellent
Applications Motors, Sensors, Magnetic Couplings, Magnetic Separators, Etc.
Magnetization Multipolar Or So
Shape Disc, Cylinder, Block, Ring, Arc, Segment, Etc.
Color Brown, Black
Tolerance 0.1mm
Property Isotropic And Anisotropic Is Avaible
Grade Residual Induction Coercive Force Intrinsic
Coercive Force		 Max.
Energy Product		 Max. Working Temperature
Br Hcb Hcj (BH)max Tw
kGs T kOe KA/m kOe KA/m MGOe KJ/m³ ℃
SmCo5 SC16 8.1-8.5 0.81-0.85 7.8-8.3 620-660 15-23 1194-1830 14-16 110-127 250
SC18 8.5-9.0 0.85-0.90 8.3-8.8 660-700 15-23 1194-1830 16-18 127-143 250
SC20 9.0-9.4 0.90-0.94 8.5-9.1 676-725 15-23 1194-1830 19-21 150-167 250
SC22 9.2-9.6 0.92-0.96 8.9-9.4 710-748 15-23 1194-1830 20-22 160-175 250
SC24 9.6-10.0 0.96- 1.00 9.2-9.7 730-770 15-23 1194-1830 22-24 175-190 250
Sm2Co17 SCS22 9.3-9.7 0.93-0.97 8.5-9.3 676-740 >18 >1433 20-23 160-183 350
SCS24 9.5-10.2 0.95- 1.02 8.7-9.6 692-764 >18 >1433 22-24 175-191 350
SCS24H 9.5-10.2 0.95- 1.02 8.7-9.6 692-764 >25 >1990 22-24 175-191 350
SCS26M 10.2-10.5 1.02- 1.05 8.5-9.8 676-780 12-18 955-1433 24-26 191-207 350
SCS26 10.2-10.5 1.02- 1.05 9.4-10.0 748-796 >18 >1433 24-26 191-207 350
SCS26H 10.2-10.5 1.02- 1.05 9.4-10.0 748-796 >25 >1990 24-26 191-207 350
SCS28M 10.3-10.8 1.03- 1.08 8.5-10.0 676-796 12-18 955-1433 26-28 207-223 350
SCS28 10.3-10.8 1.03- 1.08 9.5-10.2 796-812 >18 >1433 26-28 207-223 350
SCS28H 10.3-10.8 1.03- 1.08 9.5-10.2 796-812 >25 >1990 26-28 207-223 350
SCS30M 10.8-11.0 1.08- 1.10 8.5-10.5 676-835 12-18 955-1433 28-30 223-239 350
SCS30 10.8-11.0 1.08- 1.10 9.9-10.5 788-835 >18 >1433 28-30 223-239 350
SCS30H 10.8-11.0 1.08- 1.10 9.9-10.5 788-835 >25 >1990 28-30 223-239 350
SCS32M 11.0-11.3 1.10-1.13 8.5-10.7 676-852 12-18 955-1433 29-32 231-255 350
SCS32 11.0-11.3 1.10-1.13 10.2-10.8 812-860 >18 >1433 29-32 231-255 350
SCS32H 11.0-11.3 1.10-1.13 10.2-10.8 812-860 >25 >1990 29-32 231-255 350
SCS35 11.6-12.0 1.16-1.20 10.9-11.4 868-908 >18 >1433 32-35 255-278 350
Low Temp Coeff Sm2Co17 SCL18LT 8.4-8.9 0.84-0.89 7.9-8.4 629-668 >18 >1433 17-19 135-151 350
SCL20LT 8.9-9.4 0.89-0.94 8.3-8.9 660-708 >18 >1433 19-21 151-167 350
SCL22LT 9.4-9.8 0.94-0.98 8.7-9.3 692-740 >18 >1433 21-23 167-183 350
High Temp Resistance Sm2Co17 SCG24 9.9-10.4 0.99- 1.04 9.3-9.9 740-788 >23 >1830 23-25 183-199 400
SCG22 9.4-9.9 0.94-0.99 8.8-9.4 700-748 >23 >1830 21-23 167-183 450
SCG20 8.9-9.4 0.89-0.94 8.3-8.9 660-708 >23 >1830 19-21 151-167 500

0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators
