JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H
Specifications
Brand Name :
Gempump
Model Number :
ISG40-160
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
1 set
Price :
1000 USD/SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000 SET/Month
Delivery Time :
5-8 working days
Packaging Details :
Ply wooden box
Product :
Inline Transfer Vertical Pump Pipeline
Power :
Electric Motor
Material :
Cast Iron/ Stainless Steel
Seal :
Packing seal,Mechanical seal
Voltage :
AC220V AC380V AC415V/50HZ
Application :
Irrigation and Agriculture
Description

100m3/h 160m3/h Electric Pumps Centrifugal Vertical Pipeline Booster Pressure Water Pump

JB/T53058-93 Vertical Inline Pump Booster Pressure Water Pump 100m3/H 160m3/H

Product Description

ISW/ISG inline centrifugal pump is a high-efficient, energy-saving product successfully designed by means of adopting the property data of IS model inline centrifugal pump and the unique merits of vertical pump and strictly in accordance with ISO2858 world standard and the latest national standard JB/T53058-93 and an ideal product to replace IS horizontal pump, DL model pump and other ordinary pumps. ISG vertical inline centrifugal pump is with the characteristics below:
1. Easy to mount. Because the inlet and outlet is located on the same central line, the pump can be directly mounted on any part of the pipeline just as a valve. Covered with a rain-proof cap, it can be operated outdoors.
2. Impeller mounted directly on the long axis of the motor, pump and motor bearing arrangement is reasonable, pump operation can effectively balance the radial and axial loads, thus ensuring the smooth operation of the pump, small vibration and low noise.
3. Mechanical shaft seal, use of imported titanium alloy seal ring, medium and high temperature mechanical seal with carbide materials, anti-wearing no leakage.
4. Easy installation and maintenance, no need to open pipeline system, the rotation parts of the pump can be pulled out by removing the screws on the pump.
5. According to the needs of flow and head, the pump can be used in series or parallel operation mode.

SPECIFICATIONS FOR QW SUBMERSIBLE SEWAGE PUMP
Product Name
ISW/ISG Inline Centrifugal Pump
Structure
Single Stage
Material
Cast Iron
Head
8.5-74m (ISG) / 7-153m(ISW)
Flow
1.1-1960 m3/h(ISG) / 1.1-1345 m3/h(ISW)
Standard
ISO9001
Application
suitable for industry and urban water supply and drainage system, also for agricultural, to transfer the liquid medium like water or the physical and chemical feature like water. The temperature lower than 80 ºC.

Vertical Pipeline Booster Water Pump Model

Outlet diameter
Impeller diameter
Flow
Head
Power
mm
mm
m3/h
m
kw
65
250
21.6
60
7.5
65
315
23.7
113
22
80
250
46.7
70
18.5
80
160
93.5
28
11
80
200
87
38
15
80
315
100
125
75
100
250
100
80
37
100
200
140
45
30
100
315
160
125
90
125
160
160
32
22
120
200
150
44
30
150
125
160
20
15
150
160
150
28
18.5
200
200
179
10
11
200
400
200
50
45
200
500
200
80
90
200
250
358
16
22
500
500
400
80
132
250
400
550
50
110
250
500
550
80
185
300
315
637
28
75
300
500
626
60
160
350
250
1200
20
90
350
315
1120
38
132
350
400
1200
50
250
350
400
1120
44
220
FAQ

Q1: What is your product range?
We supply all kinds of centrifugal water pumps driven by electric or dirsel engine including single stage pumps, multistage pumps, inline pumps, split case pumps, sewage pumps, submersible pumps, deep well pumps, fire pumps, jockey pumps, booster pumps, oil pumps, irrigation pumps, chemical pumps, circulation pumps, boiler feed pumps, condensate pumps, mixed flow pumps, axial flow pumps, related pump parts and etc.

Q2: Are you a manufacturer or trading company?
We are manufacturer for nearly 10 years, and we export our water pumps by ourselves.

Q3: What information shall I provide you when I need your offer?
Normally, please send me your flow, total head, medium, medium temperature, pump material, voltage, frequency, etc so that we can quote you exactly what you need.

Q4: Can the pumps be shipped by air if I need them urgently?
Yes, of course we can deliver them by air. But I have to remind you that the freight costs will be very expensive unless you are related to Bill Gates.

Q5: Do you sell other brands water pumps? And do you accept OEM?
No, we don't sell other brands pumps, but you may send me your detailed specification requirement if our brand is ok for you. And we accept OEM.

Q6: The specification requirements of our pumps are different with what you give out,can you customize them as my data?
Yes, we can. Please send me your detailed specification requirement then we will choose the suitable pumps to quote you.
