CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
Specifications
Brand Name :
Gempump
Model Number :
CDLF2-20
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
1 set
Price :
1000 USD/SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1000 SET/Month
Delivery Time :
5-8 working days
Packaging Details :
Ply wooden box
Product :
Vertical Multistage pipeline Pump
Principle :
Centrifugal
Applications :
Chemical
Power :
Electric Motor
Voltage :
AC220V AC380V AC415V/50HZ
Temperature :
80°C (176°F)
Connection :
Flange
Position :
Horizontal
Material :
Stainless steel 304/316
Seal :
Mechanical seal
Description

Vertical multistage 304/316 stainless steel pipeline centrifugal pump

CDLF Multistage Centrifugal Pump

CDLF/CDLKF is a non-self-priming multi-stage centrifugal pump with a standard motor. The motor shaft is directly connected to the pump shaft through the pump head with a coupling. The pump can be equipped with an intelligent protector as required to effectively protect the pump from dry running, phase loss and overload.In order to meet the installation depth of the tank or container, the cavity can be installed to change the length of the pump itself. For different series length, please see the size and weight scale and the table of available product range.

Pump Material
Motor case
Aluminum
Pump case
Stainless Steel AISI304
Support
Ductile Iron
Diffuser
Stainless Steel AISI304
Impeller
Stainless Steel AISI304
Shaft
Stainless Steel AISI304
Coupling
Carbon steelk
Mechanical seal
Impregnated graphite/Silicon carbide/Viton
1. Common type is used in delivery of liquids that is clean, hot or cold, and in recycling and pressurizing of soft water.
2. Stainless steel type is used in delivery of slightly alkaline water, mineral water, distilled water, swimming pool water and other liquid containing the chloride, the temperature of the liquids shall be decreased to certain degree.
3. Flow range:1-150m3/h
4. Head range:10-305m
5. Diameter: 25-125mm
6.Temperature:-15-70℃(hot water:70-120℃)
CDLF SS316 Stainless Steel Centrifugal Pump AC220V AC380V
Vertical Stainless Steel Pipeline Pumps Working conditions:
1. used in delivery of liquids that is clean, hot or cold, non flammable, not explosive, containing no solid particles or fibers.
2. liquid temperature: -15℃~120℃
3. ambient temperature: +40℃ at most
4. The minimum pressure at inlet: according to the NPSH curve and the minimum security lift 0.5m.
CDLF Stainless Steel Pumps Application:

1.Cooling water system

2.Water supply: water transportation in water plants, boosting system in high buildings pressure boosting in main

3.Industrial liquid transportation: boiler feed, Industrial cleaning Water treatment: swimming pools.

4.Air-condition system

5.Agricultural Irrigation: sprinkler Irrigation, drip-feed irrigation Food & beverage industry

6.Fire-fighting system

FAQ
Q:Can you supply pump qualified with API standard?
A:Yes, our pump can totally meet API Standard

Q:How to customize pumps and mechanical seals ?
A:Customers could send us application data or drawings , we will select suitable pump and seal .

Q:How can I pay for my items? What is the payment you can provide?
A:Usually by T/T, 40% down payment once PI confirmed, the balance will be paid after inspection and before shipment. L/C at sight.

Q:How long is warranty?
A:1 year for main construction warranty.

Q:How long is production lead time?
A:Normally 10 days.Customize pumps and API standard pumps should be 20 days .

Q:What is the shipping terms you can provide?
A:Depnends on customer's requirements, we can provide different transportantin terms, such as EXW, FOB, CIF.

Q:Who is in charge of after-sales?
A:We have professional after sales service team, we will follow up the client's comments and suggest them good solutions. Solve client's problems and keeping the clients profit.
