Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
Specifications
Brand Name :
Gempump
Model Number :
CQB125-100-250
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
1 set
Price :
1000 USD/SET
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SET/Month
Delivery Time :
5-8 working days
Packaging Details :
Ply wooden box
Product :
Stainless Steel Magnetic Pump
Place of Orign :
China
Application :
Aicd,Alkali,Wastewater Transport
Warranty :
2 year
Lead time :
10 days
Motor voltage :
AC220V,AC380V,AC415V
Pump material :
SS304.SS316.SS316L
Power :
Electric Motor
Structure :
Single Stage Pump
Seal :
Mechanical seal,no leakage
Description

CQB High Temperature Stainless Steel Corrosion Resistant Acid Chemical Magnetic Pump

CQB stainless steel magnetic pump

1. CQB stainless steel magnetic pump

2. No seal leakage

3. modern magnetic principles

4. Mechanical sealed

Summarize
CQB stainless steel magnetic pump
The wet parts of this pump are made of full stainless steel material to perform outstanding corrosion resistance to organic acid, organic compound, alkali, neutral solution and a great many of gases, double helix carbon graphite bearing and hard alloy bearing are provided with good abrasion-resisting propertyto ensure the service life of product, it is an optimal pump for handling corrosive mediums without leakage.

2 . Technical parameters:
Performance:
Flow range: 3.2m3 / h ~ 100m3 / h
Head range: 8m ~ 50m
Motor power: 1.1kw ~ 55kw

Note: If you have special requirements, please contact our technical staff!

Model No. Caliber Capacity (m 3 /h) Head (m) Power (kW)
Voltage
Inlet(mm) Outlet(mm) (V)
CQB15-10-85 15 10 1.8 8 0.12 220/380
CQB20-15-105 20 15 3 12 0.37 220/380
CQB32-25-125 32 25 3.2 20 0.75 380
CQB32-25-145 32 25 3.2 25 0.75 380
CQB40-32-115 40 32 6.3 15 0.75 380
CQB40-32-145 40 32 6.3 25 1.5 380
CQB40-32-160 40 32 6.3 32 2.2 380
CQB50-40-125 50 40 12.5 20 2.2 380
CQB50-40-160 50 40 12.5 32 3 380
CQB65-50-125 65 50 25 20 3 380
CQB65-50-160 65 50 25 32 5.5 380
CQB80-65-125 80 65 50 20 7.5 380
CQB80-65-160 80 65 50 32 11 380
CQB100-80-125 100 80 100 20 11 380
CQB100-80-160 100 80 100 32 18.5 380

CQB Stainless Steel Pumps Application


1. Magnetic pump has advantage of compact structure, good- looking appearance, small volume, low noise, work reliable and easy to manage. It can be widely use for taking out acid, alkali liquid, oil type, rare valued liquid, volatile liquid and circular water equipment, filter accessories of chemical and industry, pharmacy, petroleum, galvanization, food-staff, film and television development, scientific research institution, National defense industry. Especially it is very suit for the take-out of leakiness, combustible, explosive liquid.


2. Corrosive liquid without solid particles, acids, alkalis, alcohol, bleach, photography solution, nitric acid, hydrochloric acid, hydrofluoric acid, acetic acid, sodium hydroxide, acetone, 4 ethylene oxide, water, salt and so on.


3. Enter the medium temperature -15~ +100, made of stainless steel, the density is not greater than 1600kg/m3, suction pressure is less than 0.2Mpa, the maximum working pressure of 1.3Mpa, transmission fluid without particles and fibers.


Major parts material form:

Corrosion Resistant ISO9001 Magnetic Centrifugal Pump 8m-50m Head Range
