4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
4 Rubber Metal Lined Horizontal Slurry Pump Tailing Transfer
Specifications
Brand Name :
Gempump
Model Number :
14/12ST-AHGEM
Certification :
ISO9001, CE
Place of Origin :
Shijiazhuang,China
MOQ :
1 set
Price :
USD1000/SET
Payment Terms :
L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Sets Per Month
Delivery Time :
5-8 working days
Packaging Details :
Plywooden Box
Product :
Horizontal centriufgal slurry pump
Material :
Chrome alloy
Structure :
Centrifugal
Power :
Electric motor
Application :
Mining
Seal :
Packing,Mechanical
Warranty :
1 year
Description

4" Anti Corrosion Horizontal Rubber/Metal Lined Tailing Transfer Non-Clogging Slurry Pump

AHGEM series pump is a horizontal, cantilevered heavy duty centrifugal slurry pump introduction

AHGEM pumps are designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements bolts reduce maintenance and minimize downtime, the horizontal centrifugal pumps will maintain high efficiencies over the wear life of its components. Rubber lined pumps expand application to chemical slurries handling, several different rubber options are available to meet different application need.

Slurry Pump Main Factures
*Horizontal, cantilevered centrifugal slurry pump
*Widely used in industries of mining, metallurgy, electric power, coal, chemicals, building,transporting abrasive or corrosive slurry etc.
*Interchangeable high wear resistant metal or pressure molded elastomer liner, so as the impeller.
*The discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installation and application
*Three seal type option:Gland packing seal, Expeller seal,Mechanical seal
*Excellent wear life,easy maintenance.
*Best total operating cost.

Product Name Heavy duty slurry pump
Material High chrome alloy Cr28, A05, A07
Standard ISO9001, ASME, ANSI
Flow rate 3.6m3-1620m3/h
Head 6-134m
Voltage 380V,415V,460V or as customer required
Working temperaturer 20ºC to 90ºC
Application Heavy duty mining process. Heavy refuse removal. Cyclone feeds
Coal preparation plant Pulp&paper. Dredging.Mineral processing.
Abrasive slurry.Tailings. High density slurries.Mill grinding.
Ash handling. Slurry feed system. Industrial processing

4

4

AHGEM SLURRY PUMP CLEAR WATER PERFORMANCE DATASHEET
MODEL MAX MATERIAL CAPACITY HEAD SPEED MAX NPSH
POWER LINER IMPELLER m3/h l/s H(m) n(r/min) η% m
KW
1.5/1B-AHGEM 15 M M 12~28 3.5~8 6~68 1200~3800 40 2~4
RU RU 10~25 3~7 7~52 1400~3400 35 2~4
2/1.5B-AHGEM 15 M M 32~12 9~20 6~58 1200~3200 45 3.5~8
RU RU 25~54 7~15 5~41 1000~2600 50 2.5~5
3/2C-AHGEM 30 M M 39~86 11~24 12~64 1300~2700 55 4~6
RU RU 36~75 10~21 13~39 1300~2100 55 2~4
4/3C-AHGEM 30 M M 86~198 24~25 9~52 1000~2200 71 4~6
4/3D-AHGEM 60
4/3C-AHGEM 30 RU RU 79~180 22~50 5~34 800~1800 59 3~5
4/3D-AHGEM 60
6/4D-AHGEM 60 M M 162~360 45~100 12~56 800~1550 65 5~8
6/4E-AHGEM 120
6/4D-AHGEM 60 RU RU 144~324 40~90 12~45 800~1350 65 3~5
6/4E-AHGEM 120
8/6E-AHGEM 120 M M 360~828 100~230 10~61 500~1140 72 2~9
8/6R-AHGEM 300
8/6E-AHGEM 120 RU RU 324~720 90~200 7~49 400~1000 65 5~10
8/6R-AHGEM 300
10/8ST-AHGEM 560 M M 612~1368 170~380 11~61 400~850 71 4~10
RU RU 540~1188 150~330 12~50 400~750 75 4~12
12/10ST-AHGEM 560 M M 936~1980 260~550 7~68 300~800 82 6
M RU 720~1620 200~450 7~45 300~650 80 2.5~7.5
14/12ST-AHGEM 560 M M 1260~2772 350~770 13~63 300~600 77 3~10
RU RU 1152~2520 320~700 13~44 300~500 79 3~8
16/14TU-AHGEM 1200 M M 1368~3060 380~850 11~63 250~550 79 4~10
20/18TU-AHGEM 1200 M M 2520~5400 700~1500 13~57 200~400 85 5~10
