Max Output Current 2500A Magnetic Separation Equipment 180KW
Max Output Current 2500A Magnetic Separation Equipment 180KW
Specifications
Brand Name :
WANDAYE
Model Number :
WS1000
Certification :
ISO9001:2008
Place of Origin :
Foshan.China
MOQ :
1set
Price :
Negotiable
Delivery Time :
Within 10 days after the advance payment is made
Packaging Details :
Film and wooden case
Model :
WS1000
Magnetic field strength(T) :
5
Input voltage(VAC) :
380
Maximum output current(DCA) :
2500
Maxiumum coil power(KW) :
180
Insulation method :
E
Description
Max output current 2500A Magnetic Separation Equipment 180KW

Product characteristic

A new model of separator with high efficiency.

High intensity magnetic field.

The temperature inside of the machine rises slowly.

Running long time and the magnetic field intensity are not easy to decrease.

Operation process

After a few minutes later(you can set the time whatever you like depending on yourself condition),close the admission valve and slurry valve, open the back slurry valve to discharge the remaining slurry in the separator, then magnetic cutting, close the admission valve, slurry valve and back slurry valve, open the iron discharging valve to discharge the magnetic material which are absorbed on the magnetic media.

Technology parameter

Model

1000

750

WS500T2 - I

W500SL

X500

Magnetic field strength(T)

5

5

5

3

5

Input voltage(ACV)

380

380

380

380

380

Maximum output current(DCA)

2500

1400

1400

1400

1400

Maxiumum coil power(KW)

180

75

75

30

45

Insulation method

E

E

E

E

E

Cooling method

Water cooling

Water cooling

Water cooling

Water cooling

Water cooling

Magnetic lumen diameter(mm)

1000

750

530

530

530

Pipe size(mm)

200

150

100

100

100

yield(m³/h)

80-200

40-100

30-70

20-50

20-50

demension(mm)

2710*2410*3500

2600*2000*3000

2200*1700*3000

1400*1700*2345

2000*1600*2800

Main machine weight(KG)

35000

16350

14100

6500

9580

Usage

Applicable for 40-400 mesh feedstock of iron elimination

Application scope

Non-metallic mineral: It is used for purifying the non-metallic mineral such as quartz, feldspar and kaolin.

Ferrous metals mineral: hematite, martite, limonite, siderite, chromite, polianite.

Non-ferrous metals mineral: used for separating wolframite from pyrope

Rare earth ore: recycle tantalum-niobium ores and monazite.

other industries: iron ore, effluent of power station disposal, disposal of contaminated chemical raw material.
