Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder
Specifications
Brand Name :
WDY
Model Number :
WG430-V-11
Certification :
ISO9001：2008
Place of Origin :
FOSHAN.CHINA
MOQ :
1set
Price :
Negotiable
Delivery Time :
Within25 days after the advance payment is made
Packaging Details :
Film And Wooden Case
Supply Ability :
50 SETS PER MONTH
Model :
WG430-V-11
Magnetic field strength（T） :
3
Inputvoltage（ACV） :
380
Maximum output current（DCA） :
20
Maximum coil power（KW） :
11
Insulation method :
E
Cooling method :
water and oil double cooling
Magnetic lumen diameter（mm） :
430
yield（T） :
1.5-6
dimension（mm） :
1500*1500* 2500
Main machine weight （KG） :
1210
Usage :
Applicable for 60-300 mesh feedstock of iron elimination
Description

3T Magnetic Separator Machine Automatic Eletromagnetic Separator for Dried-powder

Automatic 3T Dry Magnetic Separator With Water / Oil Double Cooling feldspar chemical medicine powder



Product characteristic

1. Large wrap angle and multi-magnetic-pole.

2. Can design different magnetic field intensity as the property of raw ores.

3. Doesn’t need to come over the gravity and resistance of the raw material.

4. With the mechanical vibrating equipment



Operation process

1. Feed the dry powder from the hopper, meanwhile make the separator state at the magnetizing and run a vibrator.

2. After a period ,stop feeding, cut off the magnetic device, run the other vibrator(keep the two vibrator running), poke the raffle of drain of material funnel into the iron discharge.

3. Then discharge the magnetic material absorbed on the magnetic media relying on the vibrating force.


Application scope

Electromagnetic dried-powder separators are applied in process the fine mineral, the magnetic fine ferrous mineral particle such as hematite, martite, limonite, chromite, polianite; and also fine nonferrous metals mineral particle, for example wolframite; fine rare earth mineral particle, for example eremite; and fine nonmetallic mineral particle such as feldspar, quartz, kaolin.
Electromagnetic dried-powder separators are suitable for using at the drought and water shortage area.


Technical parameter

Model WG160B-V-3 WG220B-V-3 WG300-V-7 WG220B-V-11 WG430-V-11 WG220-V-15 WG600-V-20
Magnetic field strength(t) 2 2 3 3 3 5 3
Input voltage(VAC) 380 220 380 380 380 380 380
Maximun output current(A) 15 7 20 20 20 30 40
Maximum coil power(KW) 3 3 7 11 11 15 20
Insulation category E E E E E E E
Cooling method water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling water and oil cooling
Magnetic lumen diameter(mm) 160 220 300 220 430 220 600
Yield(m3/h) 0.5-1.5 43833 1.5-4 0.5-3 1.5-6 1-3 3-8
Dimension(mm) 700*700 860*860 1320*1320 1300*110 1500*1500 1350*1100 1500*1500
*1450 *1540 *2500 *1800 *2500 *1850 *2000
Main machine weight(kg) 450 490 1020 1130 1210 1500 2000
Usage 60-300 mesh feedstock of iron elimination
