Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin
Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin
Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin
Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin
Specifications
Brand Name :
ZT
Model Number :
model 1000
Certification :
ISO9001:2008
Place of Origin :
FOSHAN.GUANGDONG.CHINA
MOQ :
1set
Price :
Negotiable
Delivery Time :
Within 25 days after the advance payment is made
Packaging Details :
Film and wooden case
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
50 SETS PER MONTH
Description

Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin

Product characteristic

1. A new model of separator with high efficiency.

2. High intensity magnetic field;

3. The temperature inside of the machine rises slowly,;

4. Long working period;

5. High efficiency in mineral processing;

6. Easy to manual and maintain.

Technology Parameter

Model

1000 Water-cooling Electromagnetic Slurry Automatic Iron Remover

1000 Oil-cooling Electromagnetic Slurry Automatic Iron Rmover

Input voltage(ACV)

380

380

Maximum output current(DCA)

2500

280

Maximum coil power(KW)

180

0-120

Cooling method

Water-cooling

Water and oil double cooling

Magnetic lumen diameter(mm)

1000

1000

Pipe size

200

219

Yield(m³/h)

80-200

80-200

Dmension(mm)

2710*2410*3500

3140*2680*3300

Main machine weight(KG)

35000

22000
Usage Applicable for 40-400 mesh feedstock of iron elimination

Operation process

Firstly, power on, then open the admission valve and slurry valve, close the return slurry valve and iron discharging valve, then magnetizing. After a few minutes later(you can set the time whatever you like depending on yourself condition),close the admission valve and slurry valve, open the back slurry valve to discharge the remaining slurry in the separator, then magnetic cutting, close the admission valve, slurry valve and back slurry valve, open the iron discharging valve to discharge the magnetic material which are absorbed on the magnetic media.

Application scope

Non-metallic mineral: Kaolin Beneficiation,Sodium potassium feldspar Beneficiation,Quartz Beneficiation

Ferrous metals mineral: hematite, martite, limonite, siderite, chromite, polianite.

Non-ferrous metals mineral: used for separating wolframite from pyrope

Rare earth ore: recycle tantalum-niobium ores and monazite.

Other industries: iron ore, effluent of power station disposal, disposal of contaminated chemical raw material.

Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin

Slurry Magnetic Separation Equipment , Electromagnetic Separator Machine for Feldspar Quartz Kaolin
