Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder
Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder
Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder
Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder
Specifications
Brand Name :
ZT
Model Number :
WG430-V-60
Certification :
ISO9001：2008
Place of Origin :
FOSHAN,CHINA
MOQ :
1set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
50 SETS PER MONTH
Delivery Time :
Within 35 days after the advance payment is made
Packaging Details :
Film and wooden case
Model :
WG430-V-60
Magnetic field strength（T） :
3.5
Inputvoltage（ACV） :
380
Maximum output current（DCA） :
100
Maximum coil power（KW） :
60
Insulation method :
E
Cooling method :
Oil and water double cooling
Magnetic lumen diameter（mm） :
430
yield（T） :
4-6
dimension（mm） :
2280*2100*2488
Main machine weight （KG） :
13500
Usage :
Applicable for 60-300 mesh feedstock of iron elimination
Description

Efficient high Magnetic intensity Separator for dry type such like kaolin feldspar quartz and plastic particles

Foshan Zhongtai Machinery Company Limited provide customers with convenient services,meantime,though the research platform cooperation and communication with people in the technology industry ,continues update the whole line science solutions of non-metallic mineraI.As a have technology and marketing services high-tech enterprise, Zhongtai Limited Wanda industry provides high-quality products, advanced production technology,excellent product quality ,perfect after- service and the support and trust from customers around the world.To up the ;set up national famous brands, moving towards the world- class enterprise.

Features

1. Electro-magnetized screens capture fine iron particles in microns.
2. Vibration motor ensures effective flow to the filter screen.
3. Limited amount of roll-in material.

Usage

1. Model WG430-V-60 is designed to remove fine iron powders from dry powdered materials and quartz sand.
to get the best results in food, chemical, plastic, ceramic, medical industries and many other.
2. Specific product is designed only to be used for secondary cell battery to handle cathode material and anode material.
Electrically conductive materials like lead, copper, zinc, tin, bronze are not used for this case.

Specifications

1. Standard high magnetic force (35000 gauss)
2. Additional Maghammer helps better flow rate.
3. Screen pitch can be selected for best results.
4. Controller included

Technical parameter

Model WG300-V-25 WG430-V-25 WG430-V-60
Magnetic field strength(ton) 2.5 2.5 3.5
Input voltage(VAC) 380 380 380
Maximun output current(A) 47 47 100
Maximum coil power(KW) 25 25 60
Insulation category E E E
Cooling method water and oil cooling water and oil cooling water and oil cooling
Magnetic lumen diameter(mm) 300 430 430
Yield(m3/h) 1-2 2-3 4-6
Dimension(mm) 1600*1500 1750*1650 2280*2100
*2075 *2075 *2488
Main machine weight(kg) 2100 2200 13500
Usage 60-300 mesh feedstock of iron elimination

Client‘s processing pictures

Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder

Dry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / PowderDry Type 3.5 Ton 100A High Intensity Magnetic Separator Machine for Quartz Feldspar Sand / Powder
