350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance
350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance
350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance
350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance
Specifications
Brand Name :
HSMAG
Model Number :
Sm2Co17
Certification :
ITAF16949 ISO9001
Place of Origin :
China
MOQ :
1PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000PCS 15Days
Delivery Time :
15 work days
Packaging Details :
Cartons, sheet metal shielding packaging
Size :
Customized
Material :
Sintered SmCo Magnet
Grade :
XG16-XG33EH
Max Working Temperature :
350℃
Tolerance :
0.05mm, 0.05mm ~ 0.1mm
Lead Time :
15 work day
Sample :
Free
Coating :
etc, Ni, Zn, Epoxy.Black Epoxy. Nickel.Silver.etc,
Description

Products Description

SmCo magnets has the highest temperature of 350℃, it has high magnetic properties,excellent temperature characteristic and corrosion resistance.It is widely used in aerospace, electronic instruments, magnetic pumps, high temperature lamps, sensors andother fields. And it can be produced in different shapes(round, square, ring, tile, bread), different properties (SmCo5 and Sm2Co17)

Different sizes: (Wafer diameter1≤R≤100mm,Square≤130mm)

Raw Material Ratio

Energy Density

ReversibleTemp.coefficient

SmCo5

Sm:Co=1:5

25MGOe

- 0.05% / ℃

Sm2Co17

Sm:Co=2:17

32 MGOe

- 0.03% / ℃.

350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance

Properties of SmC0 Magnets


350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance

Company Profile

Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.

350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance

Factory Tour

350C Sm2Co17 High Temperature Permanent Magnets 0.05mm Tolerance

Packaging Shipping
