3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
Specifications
Brand Name :
leyon
Model Number :
High Quality Malleable Fitting Equal Tees
Certification :
FM/UL
Place of Origin :
China
MOQ :
100piece
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T, D/P, D/A, MoneyGram
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
Treaded :
ISO7/1, DIN2999,NPT
Connection :
Female
Standard :
3x3/4 inch High Quality Malleable Fitting Equal Tees
Surface treatment :
Hot dipped galvanized and cold galvanized
Size :
3x3/4 inch
Material :
Iron
Description
Summary of High Quality Malleable Fitting Equal Tees

Leyon is 30 years old , bend itself to supply experience and knowledge to provide High Quality Malleable Fitting Equal Tees solutions for High Quality Malleable Fitting Equal Tees customers,in different places in High Quality Malleable Fitting Equal Tees domain. Leyon could offer speciality High Quality Malleable Fitting Equal Tees help for outstanding projects amid special construction surroundings just depend upon the consociation with world top High Quality Malleable Fitting Equal Tees makers on high-end High Quality Malleable Fitting Equal Tees products application.

Parametric form of High Quality Malleable Fitting Equal Tees
Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements
Delivery details
 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit

Top point of High Quality Malleable Fitting Equal Tees

  • The High Quality Malleable Fitting Equal Tees have outlets ranging from 1/8” through 8”.

  • High Quality Malleable Fitting Equal Tees have Perfect toughness create long using life.

  • Smooth surface of High Quality Malleable Fitting Equal Tees without any sand hole.

  • Hot dip galvanized process of High Quality Malleable Fitting Equal Tees is according to ASME, EN, BS, DIN and other international standards.

  • Our qualified High Quality Malleable Fitting Equal Tees are made by most advanced metallurgical technology high precision machining .

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4
mm 6 8 10 15 20 25 32
Dim.
(mm)		 A 19 21 25 28 33 38 45
Size Inch 3/8X1/4 1/2X1/4 1/2X3/8 3/4X1/4 3/4X1/8
mm 10X8 15X8 15x10 20x8 20X10
Dim.
(mm)		 A 23 24 26 26 28

Size Inch 3/4x1/2 1x1/4 1x3/8 1x1/2 1x3/4
mm 20x15 25x8 25x10 25x15 25x20
Dim.
(mm)		 A 30 28 30 32 35
Size Inch 11/4x3/8 11/4x1/2 11/4x3/4 11/4x1 11/2x1/2
mm 32x10 32x15 32x20 32x25 40x15
Dim.
(mm)		 A 32 34 36 40 36

Size Inch 11/2x3/4 11/2x1 11/2x11/4 2x1/2 2x3/4
mm 40x20 40x25 40x32 50x15 50x20
Dim.
(mm)		 A 38 42 46 38 40
Size Inch 2x1 2x11/4 2x11/2 21/2x1/2 21/2x3/4
mm 50x25 50x32 50x40 65x15 65x20
Dim.
(mm)		 A 44 48 52 46 49

Size Inch 3x3/4 3x1 3x11/4 3x11/2 3x2 3x21/2
mm 80x20 80x25 80x32 80x40 80x50 80x65
Dim.
(mm)		 A 52 51 55 58 64 72
Size Inch 4x1 4x11/4 4x11/2 4x2 4x21/2 3x21/2
mm 100x25 100x32 100x40 100x50 100x65 80x65
Dim.
(mm)		 A 56 60 61 70 78 76

Characteristic of High Quality Malleable Fitting Equal Tees :

  • Material: malleable iron
  • Technics: casing
  • Type: High Quality Malleable Fitting Equal Tees
  • Connection:male&female
  • size:1/8"-8"
  • Standard: ANSI, BS, DIN
  • Packing: wooden cases or as customers' demands
  • surfacetreatment:painting galvaized or as customers' demands

3x3/4 Inch Malleable Iron Pipe Fittings Black Iron Reducing Tee Round / Square Type
