ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
ANSI Standard Black Paint Malleable Iron Tee 3 Way Pipe Fitting Square Head Code
Specifications
Brand Name :
kanaif
Model Number :
figure number 130
Certification :
FM/UL
MOQ :
100piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
Color :
Galvanized
material :
malleable iron
Technics :
Casting
size :
3/8”-6“
Standard :
ANSI,BS,DIN
Head Code :
Square
Type :
tee
Description

ANSI/BS/DIN standard black paint equal Malleable Iron Pipe Fitting Banded Tees

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4 11/2
mm 6 8 10 15 20 25 32 40
Dim.
(mm)		 A 17.5 20.6 24.1 28.5 33.3 38.1 44.5 49.3
Size Inch 2 21/2 3 4 5 6 8 　
mm 50 65 80 100 125 150 200 　
Dim.
(mm)		 A 57.2 68.6 78.2 96.3 114.3 130.3 162 　

1,The equipments from DISA Denmark, DJ AMF Japan, SINTOKOGIO Japan widely used in our malleable iron tee productline, ensures the stability of product quality.

2,we use spectrometer from Oxford Instruments to check the material's quality

3,we use high heat value natural gas annealing furnace, strictly control the annealing process, improve the physical properties of the materials

4,Each pipe fitting tee after air tightness test, ensure no leakage

5,Strictly control the size of the thread, to ensure accuracy

6,The pipe fittings have outlets ranging from 1/8” through 8”

7,Good toughness with long working life.

8,Smooth surface without any sand hole,high quality products

9,avg. thickness of zinc coating is higher than 86 um specified in ASME, EN(70um), DIN(70um), SI(78um)

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements

Delivery details

 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit
