Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
Specifications
Brand Name :
leyon
Model Number :
OEM 90 Degree Street Banded Elbow
Certification :
FM/UL
Place of Origin :
China
MOQ :
100piece
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T, MoneyGram
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
Specification :
Elbow, socket, Tee, Union, Bushing, Plug
Material :
Iron
Standard :
ANSI,BS,DIN
Dimension :
A:32mm B:34mm
Chemical property :
(C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Testing pressure :
2.5Mpa
Description

Malleable Iron Pipe Fitting 45 Or 90 Degree Street Banded elbow

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements

Delivery details

 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit

Sketch out 90 Degree Street Banded Elbow

Size Inch 3/8X1/4 1/2x1/4 1/2x3/8 3/4x3/8 3/4x1/2
mm 10X8 15X8 15X10 20X10 20X15
Dim.
(mm)		 A 23 26 26 28 30
B 23 26 26 28 31
Size Inch 1x1/2 1x3/4 11/4x1/2 11/4x3/4 11/4x1
mm 25X15 25X20 32X15 32X20 32x25
Dim.
(mm)		 A 32 35 34 36 40
B 34 36 38 41 42

Information of 90 Degree Street Banded Elbow

Blast-Furnace smelting + electric furnace adjustment duplex smelting technology, 48 hours – 3 sections –electric annealing technology,comprehensively ensure our products’ quality to be the best .

Take “six check + two inspect +one examine” measures, using Germany made FOUNDRY-MASTER Xline to check each pack of liquid iron’s chemical composition , ensure low defect rate and stable product quality .

Carefully choose multiple vendors, using high quality raw material , remove all the impurities which is bad product quality control

Small package numbers , which is easier for handle ; Carefully choose high quality non-recycled plastic made double-woven bag , make the product to be more break –resistant , no need worry about broken bag during handing process.

Malleable Iron 45 Degree Pipe Elbow , Water Pipe Street Elbow High Tenacity
