10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
10mm Hydraulic Swivel Elbow Pipe Fittings , High Pressure Water Hose Fitting
Specifications
Brand Name :
leyon
Model Number :
High Pressure Elbow Fitting
Certification :
FM/UL
Place of Origin :
China
MOQ :
100piece
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T, MoneyGram, D/A, D/P
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
head shape :
round
Technics :
Casting
surface treatment :
Hot dipped galvanized and cold galvanized
OEM :
High Pressure Elbow Fitting
thread :
NPT
Usage :
Oil Gas Water Industrial
certificate :
BSI, ISO9001,FM,UL
color :
white
Description

High Pressure Hose Fitting Hydraulic Swivel 10mm Hose Barb Elbow Fitting

Attach Excel list of High Pressure Elbow Fitting

Size Inch 1/8 1/4 3/8 1/2 3/4 1 11/4 11/2
mm 6 8 10 15 20 25 32 40
Dim.
(mm)		 A 19 21 25 28 33 38 45 50
Size Inch 2 21/2 3 4 5 6
mm 50 65 80 100 125 150
Dim.
(mm)		 A 50 69 78 96 115 1301

Size Inch 3/8X1/4 1/2x1/4 1/2x3/8 3/4x3/8 3/4x1/2
mm 10X8 15X8 15X10 20X10 20X15
Dim.
(mm)		 A 23 26 26 28 30
B 23 26 26 28 31
Size Inch 1x1/2 1x3/4 11/4x1/2 11/4x3/4 11/4x1
mm 25X15 25X20 32X15 32X20 32x25
Dim.
(mm)		 A 32 35 34 36 40
B 34 36 38 41 42

Size Inch 11/2X1/2 11/2x3/4 11/2x1 11/2x11/4 2x1/2
mm 40X15 15X8 40X25 40X32 50X15
Dim.
(mm)		 A 36 39 42 46 38
B 42 44 46 28 48
Size Inch 2x3/4 2x1 2x11/4 2x11/2 21/2x1
mm 50X20 50X25 50X32 50X40 65x25
Dim.
(mm)		 A 40 44 56 52 56
B 50 52 58 55 63

Discribe :

  • High Pressure Elbow Fitting processing production using Danish imports of Di sand, Japan's long East and the new East automatic production lines to ensure product quality.
  • Every batch sample will be examined by Oxford Instruments spectrometer to ensure quality.
  • There are three kind of malleable cast iron :Black heart malleable cast iron (KTH) , Pearlite malleable cast iron (kTZ) and White heart malleable cast iron (KTB) .
  • The material of our products are KTH , the national standard of Material grade need to arrive to KTH300-06 , the standard of our products is KTH330-08 . the KTH stand for Black heart malleable cast iron , the 300 , 330 , 350 is for extending and 06,08,12 is for stretching.All this is stand for toughness .
Size Inch 21/2X11/2 3x21/2 21/2x2 3x11/2
mm 65X40 80X65 65X50 80X40
Dim.
(mm)		 A 64 82 61 58
B 69 85 66 72
Size Inch 3x2 4x21/2 4X3
mm 80X50 100X65 100X80
Dim.
(mm)		 A 73 78 84
B 78 90 92

What’s malleable cast iron ?

Malleable iron is cast as white iron, the structure being a metastable carbide in a pearlitic matrix. Through an annealing heat treatment, the brittle structure as first cast is transformed into the malleable form.
