FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
FM UL CE Approved Ductile Iron Grooved Pipe Fittings Flexible Grooved Coupling
Specifications
Brand Name :
leyon
Model Number :
grooved reducer
Certification :
FM/UL
Place of Origin :
China
MOQ :
100piece
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
function :
fire protection,water supply, pulp transportation,etc.
type :
reducer
size :
1-24"
Technics :
casing
certificate :
UL/FM approved
Product name :
grooved reducer
name :
ductile iron reduceing flexible
item :
factory grooved reducer
Description

cast iron pipe fitting duplex 2205 grooved reducing cross grooved adaptor

Product details

1. Material: Ductile iron
2. Standard: American/BS/DIN standard
3. Certification:UL, FM, BIS, CCC, ISO 9001

4. Size: customized

5. We have pressure testing machine to test the quality

6. Smooth mouth without burr

7. Wall thickness uniformity

Our factory

Leyon is one of the largest pipe fittings manufacturer.

We has been concentrating in the designing and manufacturing of pipe connecting

more than 20 years.With advanced technology and equipment,

including R&D center, 3 fully autocasting lines,

CNC machine tools and autofinishing lines,

we can ensure excellent quality and reasonable price.
We get certificate of ISO9001:2008 and our products ranged from

Pipe coupling and fittings Grooved Pipes, Valves, etc,

which are widely applied in petrochemical industry,

municipal engineering, construction industry, water power and fire protection.

Looking forward to the opportunity to cooperate with you in near future.

Table-form for grooved reducer

Nominal
Size
mm/in		 Pipe
O.D.
mm/in		 Working
Pressure
PSI/Mpa		 Dimensions
L
mm/in		 Certificate
65
21/2		 76.1
3.000		 362.5
2.5		 76.25
3		 3C UL FM
80
3		 88.9
3.500		 362.5
2.5		 82.5
3.248		 3C UL FM
100
4		 114.3
4.5		 362.5
2.5		 92.5
3.642		 3C UL FM
125
5		 139.7
5.250		 362.5
2.5		 110
4.33		 3C UL FM
150
6		 165.1
6.500		 362.5
2.5		 122.5
4.883		 3C UL FM
200
8		 219.1
8.625		 362.5
2.5		 164
6.457		 3C UL FM

Essential information of grooved reducer

Material Ductile lron
Standard ASTM A536 Gr.65—45—12 EN1563.JIS G5502
Physical property Tensile strength>=310Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Surface painted
Color red, blue, white
Model Ductile iron grooved pipe fittings (Rigid coupling,45°elbows,grooved pipe fitting 90°elbows,reducing tee,grooved cross,flange coupling,cap ect.)
Connection Female, welding, flange
Shape Equal, reducing
Certificate FM,UL BSI,ANSI,ISO9001, 3C
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements
Delivery details According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit
