NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
Specifications
Brand Name :
leyon
Model Number :
Hot Galvanized Malleable Fittings elbow
Certification :
FM/UL
Place of Origin :
China
MOQ :
500piece
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T, D/P, D/A, MoneyGram
Supply Ability :
10000piece/week
Delivery Time :
25-35days
Packaging Details :
200piece/carton
Specification :
Elbow, socket, Tee, Union, Bushing, Plug
Item :
1/8 inch Hot Galvanized Malleable Fittings Tees
Application :
Steam, air, gas and oil pipes
Technics :
sophisticated metallurgical
technology :
advanced metallurgical and processing
Treaded :
ISO7/1, DIN2999,NPT
Size :
1/8 inch
Dimensions :
19 mm
Description

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

Surface processing:

  1. Rough casting
  2. Rough shot
  3. Rough casting test
  4. Annealing
  5. Polished
  6. Shaping
  7. Flat
  8. Fine shot
  9. Cooked rough
  10. Pickled
  11. Hot galvanized
  12. Hot galvanized Product.
  • MALLEABLE CAST IRON - High quality malleable cast iron is perfectly anti-rust in oil and gas. Durable and no flexibility cast iron always used in many industry buildings. But malleable cast iron is unprocessed and needs to be cleaned and sealed to prevent rust before use.

  • WIDE APPLICATION - You can use these pipe fittings to install a durable iron frame f or your pipe shelving, wall lamp or other home décor.

  • EASY TO USE - These pipe fittings are threaded, just connect the threaded rods or pipes to the tees and elbows, you can easily to build any shape of frame and shelf for a DIY furniture as you like. Don’t need any screws.

  • 100% MONEY-BACK GUARANTEE - We offer 90 days unconditional refund or replacement service if there are any quality issues. Contact us at any time and we will give you a satisfying answer. Just take a chance of our corner braces and we promise that you will not be disappointed.

Material Malleable iron
Standard Thread: ISO 7/1
Dimension ISO 49, DIN 2950,EN10242
Chemical property (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
Physical property Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
Testing pressure 2.5Mpa
Working pressure 1.6Mpa
Type Beaded with ribs or banded with ribs
Beaded without ribs or banded without ribs
Round/square
Surface Galvanized/ no galvanized
Color White/black
Model Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
Connection Male, Female
Shape Equal, Reducing
Certificate BSI,ANAB,ISO9001,FM,UL
Application Suitable for pipe connect of steam, air, gas, oil and so on
Buyer’s drawings or designs are available
Package Cartons without pallet
Cartons with pallet
Double woven bags
Or as buyer’s requirements

Delivery details

 According to the quantities and specifications of each order
Normal delivery time is from 30 to 45 days after receiving the deposit

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration

NPT 90 Degree Elbow Malleable Iron Fittings For Shelving Decoration
