1650KVA 50HZ LED Panel Control 40kw Silent Cummins Marine Genset
1650KVA 50HZ LED Panel Control 40kw Silent Cummins Marine Genset
1650KVA 50HZ LED Panel Control 40kw Silent Cummins Marine Genset
1650KVA 50HZ LED Panel Control 40kw Silent Cummins Marine Genset
Specifications
Brand Name :
JV
Model Number :
JVL-51
Certification :
BS
Place of Origin :
China
MOQ :
1set
Price :
$2000-3000pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000set/Month
Delivery Time :
45-65 days
Packaging Details :
Standard export package
Product name :
40kw Cummins Marine Genset
Control system :
LED panel
Button :
Convenient and rapid
Fuel filler :
In non-stopped state
Gensets power :
Prime/Standby
Power :
Yuchai/Shangchai/Weichai
Standards :
GB/T2820/IEC34-1
Related Voltage :
380/400/200
Description

Marine Diesel Generator Set Silent Diesel Generator 40kw Cummins Marine Genset

28-1650KVA/50HZ
　 Gensets Technical Data of Diesel Engine(50hz/1500rpm)
I Model 　 Engine Fuel Cylinderx Displa- Compr- Asp. I
　 　 　 model consumption BorexStroke ceme nt ession 　
　 　 　 　 G/kw.h L/h {Qtyxmnixnim) (L) Ratio 　
XYT-C28 28 4B3.9-G1 245 7.1 4x102x120 3.9 17.3:1 N/A
XYT-C33 33 4B3.9-G2 229 6.7 4x102x120 3.9 18.0:1 N/A
XYT-3541 41 4BT3.9-G1 229 10 4x102x120 3.9 17.3:1 TC
XYT-3545 45 4BT3.9-G2 214 9.3 4x102x120 3.9 18.0:1 TC
XYT-C66 66 4BTA3.9-G2 212 14.9 4x102x120 3.9 17.3:1 TC
XYT-C80 83 4BTAA3.9-G11 208 17.6 4x102x120 3.9 17.3:1 TC
　 110 6BT5.9-G1 208 21.7 6x102x120 5.9 17.3:1 TC
　 110 6BT5.9-G2 214 22.3 6x102x120 5.9 17.3:1 TC
XYT-C140 138 6BTA5.9-G2 211 27 6x102x120 5.9 17.3:1 TC
XYT-C150 150 6BTAA5.9-G2 208 30 6x102x120 5.9 17.3:1 TC
XYT-C165 165 6BTAA5.9-G12 203 34 6x102x120 5.9 17.3:1 TC
　 206 6CTA&3・G1 215 42 6x114x135 8.3 17.3:1 TC
　 206 6CTA&3・G2 212 42 6x114x135 8.3 17.3:1 TC
XYT-C220 220 6CTAA83G2 205 45 6x114x135 8.3 18.0:1 TC
　 275 6LTAA8.9-G2 197 53 6x114x145 8.9 1661 TC
　 275 6LTAA8.9-G3 195 54 6x114x145 8.9 16.6:1 TC
　 275 NT855-GA 191.8 53.4 6x140x152 14.0 15:1 TC
　 275 MTA11-G2A 220 60.56 6x125x147 10.8 16.1:1 TC
XYT-C330 330 NTA855-G1A 195 61.3 6x140x152 14.0 14.5:1 TC
　 358 NTA855-G1B 208.8 71.4 6x140x152 14.0 14:1 TC
　 358 MTAA11-G3 188 62.37 6x125x147 10.8 15:1 TC
　 385 NTA855-G2A 192.6 71.9 6x140x152 14.0 14:1 TC
　 385 NTA855-G4 197.2 75.3 6x140x152 14.0 14:1 TC
　 413 6ZTAA13-G3 189 76.5 6x130x163 13.0 17:1 TC
　 413 NTAA855-G7A 200.5 89.2 6x140x152 14.0 14:1 TC
XYT-35450 450 NTAA855-G7A 200.5 89.2 6x140x152 14.0 14:1 TC
　 495 6ZTAA13-G2 192 89.1 6x130x163 13.0 17:1 TC
XYT-35400 495 QSZ13-G2 191 88.8 6x130x163 13.0 17:1 TC
　 495 KTA19-G3 204 97 6x159x159 18.9 13.9:1 TC
　 550 QSZ13-G3 193 101.0 6x130x163 13.0 17:1 TC
　 550 KTA19-G3A 203 106.99 6x159x159 18.9 13.9:1 TC
XYT-C600 605 KTXKA19-G5 203 112.25 6x159x159 18.9 13.5:1 TC
XYT-C650 650 KTAA19-G8 206 126.75 6x159x159 18.9 13.9:1 TC
XYT-C688 688 KTAA19-G6A 206 134.75 6x159x159 18.9 13.9:1 TC
XYT-C729 729 QSKT19-G3 206 139.11 6x170x170 19.0 16.0:1 TC

1650KVA 50HZ LED Panel Control 40kw Silent Cummins Marine Genset
