Seawater Treatment Equipment 1000lph Brackish Water Treatment Plant Salt Water to Drinking Water Machine

Specification

Performance and Features

1. Reverse osmosis seawater desalination technology is mature and advanced, the desalination rate is up to 99.4%.

2. Energy saving design, low energy consumption and low cost of water production.

3. Rigorous process design ensures long system life and low ma intenance costs.
4. Easy to operated and maintained, cleaned and repaired without disassemble, easy to managed.
5. Equipment Combination Type: Frame Type, Container Type.
6. Customized according to customers' needs.

Configuration

1. RO Membrane: USA DOW/ HYDRANAUTICS/GE

2. Pressure Vessel: First Line, FRP Material
3. Raw Water Booster Pump: Grundfos/ CNP
4. High Pressure Pump: Grundfos/ CNP

5. Device Framework: Indus try-standard thick- walled stainless steel tube, and pipe outer surface is polished
6. Pipeline: The high-pressure side pipe line adopts dual-phase steel or stainless steel pipelines andhigh-pressure hoses. Low-pressure side pipe uses UPVC pipe
7. Electric Element: OMRONS PLC, ABB Frequency inverter, Schne ider Electric element

Product Introduction

Brackish water desalination equipment is suitable for high-salinity areas and seawater inverted areas. It uses reverse osmosis membrane elements imported from the United States, domestic high-quality pressure vessels, and imported high-pressure pumps, with reasonable pretreatment equipment, which can effectively remove inorganic salts in water , Heavy metal ions, organic matter, bacteria and germs and other harmful ingredients, desalinize brackish water into high-quality water that meets the national drinking water standards. Carry out detailed analysis and special design according to the local water quality, strive to be efficient and durable, and make the desalinated water completely meet the national drinking water quality standard (GB5749-2006), and completely solve the drinking water problem in water-scarce areas. As the groundwater quality varies from place to place, it is best for users to provide detailed local water quality analysis reports to ensure that a reasonable and economical configuration is designed to achieve the best water output effect.
