Carbon Steel Ship Hall Spek Type Anchor Hot Dip Galvanized
Carbon Steel Ship Hall Spek Type Anchor Hot Dip Galvanized
Carbon Steel Ship Hall Spek Type Anchor Hot Dip Galvanized
Carbon Steel Ship Hall Spek Type Anchor Hot Dip Galvanized
Specifications
Brand Name :
JV
Model Number :
JVL-122
Certification :
CCS,BV,KR,ABS
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000pcs/Month
Delivery Time :
35-55 days
Packaging Details :
Standard export package
Material :
Carbon Steel
Surface :
Black color
Application :
Ships / Vessels
Product name :
Heavy-duty anchors
Packing :
Wooden box
Name :
Ship anchor
Surface treatment :
Black Painted
Oem :
Welcome
Description

Ship Anchors Hall Anchor Spek Anchor With CCS ABS BV Cert High Holding Power Anchor

Chongqing Juvi marine machinery company is an integrated marine technology company that presently specializes in product design, production, and sales. Juvi company is administered by the marine equipment production systems. Every factory that our partnership has passed these, ABS, DNV, LR, NK, RINA, ISO9002, TS16949, UL, and other related systems authentication.
More than 10 years of accumulated experience, high-quality products, coupled with our philosophy of absolute integrity in all business dealings have earned us unanimous praise from old and new clients alike, as well as a distinctive reputation in the industry.

Product Details:


· High Holding Power anchor
· Material: Carbon steel
· Nominal Weight: 160kg to 50000kg
· Finishing: black painting or hot dip galvanized
· Optional Material: Stainless steel
· Certificate: DNV-GL, BV, ABS, LRS, RINA, RS, CCS


No.
Nominal
Weight(KG)
Size(mm)
H h h1 L L1 B1
A B C
JV10-40 40 557 557 430 303 67 430 303 198
JV10-60 60 637 637 492 347 76 492 347 227
JV10-100 100 760 760 590 410 90 584 410 227
JV10-125 125 814 814 629 443 97 629 443 290
JV10-150 150 866 866 665 470 103 760 470 308
JV10-180 180 919 919 718 500 109 710 500 327
JV10-240 240 1019 1019 788 552 120 790 552 361
JV10-300 300 1095 1095 850 595 130 844 595 388
JV10-360 360 1160 1160 898 630 138 898 630 412
JV10-420 420 1160 1160 946 660 145 946 660 434
JV10-480 480 1222 1222 986 690 152 988 690 454
JV10-570 570 1355 1355 1042 732 161 1042 732 481
JV10-660 660 1356 1356 1093 769 169 1096 769 506
JV10-780 780 1506 1506 1170 813 178 1160 813 535
JV10-900 900 1580 1580 1215 855 188 1220 855 560
JV10-1020 1020 1645 1645 1268 855 188 1220 855 560
JV10-1140 1140 1705 1705 1316 926 203 1319 926 605
JV10-1290 1290 1778 1778 1378 891 195 1268 891 584
JV10-1440 1440 1844 1844 1448 965 203 1379 965 630
JV10-1590 1590 1906 1906 1511 1035 226 1475 1035 677
JV10-1740 1740 1966 1966 1571 1068 234 1517 1068 698
JV10-1920 1920 2031 2031 1602 1104 241 1568 1104 722
JV10-2100 2100 2093 2093 1651 1120 245 1560 1120 732
JV10-2280 2280 2150 2150 1716 1165 225 1657 1165 763
JV10-2460 2460 2207 2207 1785 1194 262 1700 1194 784
JV10-2640 2640 2259 2259 1843 1222 265 1730 1222 796
JV10-2850 2850 2318 2318 1890 1253 275 1787 1253 822
JV10-3060 3060 2374 2374 1935 1283 282 1832 1283 841
JV10-3300 3300 2432 2432 1985 1317 288 1880 1317 862
JV10-3540 3540 2490 2490 2032 1349 295 1926 1394 883
JV10-3780 3780 2547 2547 2077 1376 302 1965 1376 902
JV10-4050 4050 2610 2610 2125 1406 309 2008 1406 924
JV10-4320 4320 2695 2695 2171 1435 316 2051 1435 943
JV10-4590 4590 2712 2712 2216 1465 332 2093 1465 962
JV10-4890 4890 2769 2769 2263 1498 329 2135 1498 984
JV10-5000 5000 2800 2800 2317 1510 332 2156 1510 992
JV10-5610 5610 2899 2899 2369 1569 345 2234 1569 1031
JV10-6000 6000 2965 2965 2422 1605 352 2284 1605 1054
JV10-6450 6450 3037 3037 2482 1644 361 2340 1644 1080
JV10-6900 6900 3100 3100 2538 1681 369 2393 1681 1105
JV10-7350 7350 3100 3100 2592 1688 370 2400 1688 1109
JV10-7800 7800 3235 3235 2644 1752 385 2493 1752 1152
JV10-8300 8300 3363 3363 2699 1788 393 2545 1788 1176
JV10-8700 8700 3355 3355 2742 1816 399 2585 1816 1195
JV10-9300 9300 3430 3430 2804 1850 417 2632 1850 1226
JV10-9900 9900 3502 3502 2863 1896 417 2699 1896 1248
JV10-10500 10500 3571 3571 2920 1934 425 2752 1934 1273
