Specifications
Brand Name :
FLORESCENCE
Model Number :
FL rubber fender(139)
Certification :
CCS,ABS,DNV,LR,ISO9001
Place of Origin :
Shandong,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
100 pcs/month
Delivery Time :
5-10 work days
Packaging Details :
nude,container
Main material :
Natural rubber:imported from Thailand
Cord fabric :
1880D2,100% raw silk
Warranty period :
24 months
Design using life :
Usually 10 years
Color :
Black,white,grey
Chain :
Hot galvanizing or stainless steel
Description

Used For Ocean Guard And Offshore With Yokohama Pneumatic Marine Rubber Fender

In order to protect your maritime values, FL-RUBBER strongly recommends the use of ISO certified Pneumatic Fenders while performing the high quality needed for safe berthing during ship to ship operations involving bunkering or discharging of oil or gas, and ship to port operation

Advantages of FL marine rubber fender:


* Absorb more energy,less reverse impact on the ships


* Not being bent out of shape under pressure


* Good air tightness,safety and reliability


* High shock absorption,low counterforce and enhance port ability


* Produce according to ISO17357:2002 completely

* Optional tire and chain,can provide chain with hot galvanizing or stainless steel(304,312,316)


* Optional end fittings for the better suitable of applications

Technical performance of marine rubber fender

Specification

DXL(m)

0.05Mpa(Initial pressure 0.05Mpa) (Initial pressure 0.08Mpa)
Weight(kg) Reaction force(KN)

GEA

(KJ)

Weight

(kg)

Reaction force(KN)

GEA

(KJ)

0.5X1.0 25 674 6 25 85 8
0.6X1.0 32 74 8 32 98 11
0.7X1.5 50 137 17 50 180 24
1.0X1.5 80 182 32 80 239 45
1.0X2.0 100 257 45 125 338 63
1.2X2.0 120 297 63 165 390 88
1.35X2.5 165 427 102 226 561 142
1.5X3.0 315 579 153 370 761 214
2.0X3.5 590 875 308 632 1150 430
3.0X5.0 1880 2000 1050 2155 2709 1571
3.0X6.0 2160 2488 1312 2470 3292 1888
3.3X4.5 2020 1884 1175 2300 2476 1640
3.3X6.0 2300 2783 1675 2600 3652 2338
3.3X6.5 2700 3015 1814 3080 3961 2532
3.3X10.6 4403 5257 3067 5020 6907 4281
4.5X9.0 6554 5747 4752 7470 7551 6633

All dimensions are approximate

* “Guaranteed energy absorption” represents the guaranteed energy absorption at 60% deflection.

* Tolerance of reaction force and deflection at guaranteed energy absorption are as follows: Reaction ±10% Deflection ±10%

* Each reaction and energy absorption are measured under static condition

* Testing pressure rate indicates the testing pressure at factory

* Weight of fender body and net may vary by ±10%

FAQ

Q1: What’s your delivery time and payment terms?

A: Delivery time is according to customers’ size and order qty.The payment terms you could choose are T/T,L/C at sight,Western Union and so on.

Q2: What’s certificates can your company provide?

A: We can provide CCS,ABS,DNV,LR,BV certificates.

Q4: What about your warranty time?

A: Our warranty period is 24 months.During this time,any problems about products from our factory,we solemn promise to change and repair them for free;if problems from customers’ improper operating,we could provide free guidance and repair materials
