Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Ship Barge Marine Pneumatic Rubber Fender ISO17357 Approved
Specifications
Brand Name :
FLORESCENCE
Model Number :
FL rubber fender(98)
Certification :
CCS,ABS,DNV,LR,ISO9001
Place of Origin :
Shandong,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
100 pcs/month
Delivery Time :
5-10 work days
Packaging Details :
nude,container
Cord fabric :
1880D2,100% raw silk
Diameter :
from 0.3-4.5m,customzied
Length :
from 0.5-9.0m,customized
Warranty period :
24 months
Certificates :
CCS,ABS,DNV,BV,LR
Design using life :
More than 10 years
Material :
Natual rubber:RSS3,imported from Thailand
Color :
Black,grey,white
Description

Iso 17357 Approved Ship Barge Rubber Fender / Marine Rubber Fender

In order to produce the qualified and famous China Brand of pneumatic fenders , FL RUBBER invested the advanced production and test equipments, and invited the foreign experienced engineers of pneumatic fenders, which ensure all FL pneumatic fenders are manufactured comply with ISO17357:2002. Therefore, FL-RUBBER is the unique manufacturer of ISO17357 qualified Pneumatic Fenders in China.

In order to protect your maritime values, FL-RUBBER strongly recommends the use of ISO certified Pneumatic Fenders while performing the high quality needed for safe berthing during ship to ship operations involving bunkering or discharging of oil or gas, and ship to port operation


Advantages of FL marine rubber fender:


* Absorb more energy,less reverse impact on the ships


* More flexible ,easy installation


* Long term service life


* Not being bent out of shape under pressure


* Good air tightness,safety and reliability


Technical performance of marine rubber fender

Specification
DXL(m)

 0.05Mpa(Initial pressure 0.05Mpa) (Initial pressure 0.08Mpa)
Weight(kg) Reaction force(KN)

GEA
(KJ)

Weight
(kg)

 Reaction force(KN)

GEA
(KJ)
2.0X3.5 590 875 308 632 1150 430
2.5X4.0 1050 1381 663 1110 1815 925
2.5X5.5 1333 2019 943 1410 2653 1317
3.0X5.0 1880 2000 1050 2155 2709 1571
3.0X6.0 2160 2488 1312 2470 3292 1888
3.3X4.5 2020 1884 1175 2300 2476 1640
3.3X6.0 2300 2783 1675 2600 3652 2338
3.3X6.5 2700 3015 1814 3080 3961 2532
3.3X10.6 4403 5257 3067 5020 6907 4281
4.5X9.0 6554 5747 4752 7470 7551 6633
4.5X12 8739 7984 6473 9960 10490 9037
Note:The weight is the fender body weight(without tires and chain),with weight error of ±10% and counterforce error of ±10%

Notes about FL rubber fender

* Frequently check whether the fender body si damaged and whether the pressure is normal,and the valve core must be replaced every six moths

* The steel wire should wrap the rubber pipe,when trying steel wire to pneumatic rubber fender in case the fender is stabbed

* The surface or subject next to the pneumatic rubber fender can’t be hard and sharp-pointed in case the pneumatic rubber fender is stabbed

* The accessories and jip’s nuts can’t be loose when testing the internal pressure

* The rope net should be reliable,the steel wire used for hanging metal parts and the hook link can’t be tied in disorder.
