Specifications
Brand Name :
Florescence
Model Number :
Florescence rubber airbag(78)
Certification :
CCS,ABS,DNV,LR,ISO9001
Place of Origin :
Shandong,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
30PCS/Month
Delivery Time :
5-10 days
Packaging Details :
container,pallet,wooden box
Material :
Natural rubber:RSS3,imported from Thailand
Cord Fabric :
1880D2,100% raw silk
Warranty period :
24 months
Thickness :
More than 5.5mm
Layer :
3-12 layers
Working pressure :
0.17-0.33Mpa
Description

Iso9001 Certification Ship Launching And Landing Inflatable Marine Rubber Airbag

Advantages of Florescence marine rubber airbag

1. Big carrying capacity

2. High capacity against compression and twisting

3. New design of anti-bursting construction at the end

4. Optimized structural layout

5. Durable aging resistance and anti-wear characteristic

6. Higher flexibility and damping capacity

Standard specifications of Florescence marine rubber airbag

1> Diameter (D): From 0.3m to 2.2 m.

2> Effective Length (EL): From 6m to24m.

3> Total Length (TL): From 7m to28m.

4> Other specification of ship launching airbags also available upon customer’s request


The structure of Florescence rubber airbag:

It consists of a bag body and an iron-end component. The bag body is manufactured by vulcanizing the preliminary shaped airbag made of base rubber and reinforced fiber material. The material of the iron- end component is metal, and it is connected to the bag body firmly.

Working pressure of Florescence marine rubber airbag:

Diameter Layer Work pressure Diameter Layer Work pressure
D=0.8M 3 0.13 Mpa D=1.5M 3 0.07 Mpa
4 0.17 Mpa 4 0.09 Mpa
5 0.21 Mpa 5 0.11 Mpa
6 0.25 Mpa 6 0.13 Mpa
7 0.30 Mpa 7 0.15 Mpa
8 0.33 Mpa 8 0.18 Mpa
D=1.0M 3 0.10 Mpa D=1.8M 3 0.06 Mpa
4 0.13 Mpa 4 0.08 Mpa
5 0.17 Mpa 5 0.09 Mpa
6 0.20 Mpa 6 0.11 Mpa
7 0.25 Mpa 7 0.13 Mpa
8 0.28 Mpa 8 0.15 Mpa
D=1.2M 3 0.09 Mpa D=2.0M 3 0.05 Mpa
4 0.11 Mpa 4 0.07 Mpa
5 0.14 Mpa 5 0.08 Mpa
6 0.17 Mpa 6 0.10 Mpa
7 0.20 Mpa 7 0.12 Mpa
8 0.23 Mpa 8 0.14 Mpa


FAQ



Q1: What’s your delivery time and payment terms?
A: Delivery time is according to customers’ size and order qty.The payment terms you could choose are T/T,L/C at sight,Western Union and so on.

Q2: How can I get samples from you?
A: We are honored to provide you samples for check quality.Customers just confirm freight collect and then we could send out the sample by FedEx,DHL,UPS,TNT and so on.

Q3: What’s certificates can your company provide?
A: We can provide CCS,ABS,DNV,LR,BV certificates.

Q4: What about your warranty time?
A: Our warranty period is 24 months.During this time,any problems about products from our factory,we solemn promise to change and repair them for free;if problems from customers’ improper operating,we could provide free guidance and repair materials
