Specifications
Brand Name :
Florescence
Model Number :
Florescence rubber airbag(107)
Certification :
CCS,ABS,DNV,LR,ISO9001
Place of Origin :
Shandong,China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
30PCS/Month
Delivery Time :
5-10 days
Packaging Details :
container,pallet,wooden box
Cord Fabric :
1880D2,100% raw silk
Standard :
CB/T-3795,CB/T-3837,ISO14409
Warranty period :
24 months
Design using life :
10 years
Working pressure :
0.17-0.33Mpa
Quality :
Excellent
Description

Used For Vessel Salvage Heavy Moving With Inflatable Marine Rubber Airbag

Advantages of Florescence inflatable rubber airbag

1. New design of anti-bursting construction at the end

2. Optimized structural layout

3. Higher flexibility and damping capacity

Standard specifications of Florescence marine rubber airbag

1> Diameter (D): From 0.3m to 2.2 m.

2> Effective Length (EL): From 6m to24m.

3> Total Length (TL): From 7m to28m.

4> Other specification of ship launching airbags also available upon customer’s request


Working pressure of Florescence marine rubber airbag:

Type Diameter Pressure marine airbag can load
Working hight

Static

Pressure load

 Dynamic pressure load

Plan

airbag

 0.8m 0.06mpa 0.3m 8 ton 4 ton
1m 0.05mpa 0.3m 9 ton 5 ton
1.2m 0.05mpa 0.35m 10 ton 6 ton
1.5m 0.05mpa 0.7m 12 ton 8 ton
1.8m 0.04mpa 0.8m

Slope

airbag

 0.8m 0.06mpa 0.3m 9.6 ton 6 ton
1m 0.05mpa 0.3m 10.8 ton 7.5 ton
1.2m 0.05mpa 0.35m 12 ton 9 ton
1.5m 0.05mpa 0.7m 14.4ton 12 ton
1.8m 0.04mpa 0.8m 18 ton 15 to
Intertwine airbag 0.8m 0.06mpa 0.3m 12 ton 7.2 ton
1m 0.05mpa 0.3m 13.5 ton 9 ton
1.2m 0.05mpa 0.35m 15 ton 10.8 ton
1.5m 0.05mpa 0.7m 18 ton 14.4 ton
1.8m 0.4mpa 0.8m 22.5 ton 18 ton

Hoisting and moving airbags: They can be widely used for moving various large prefabricated reinforced-concrete products (such as caisson, box culvert, and bridge), oil drilling equipment and integrated building, etc

Our service

Pre-sale service:Every product will be inspected before shipment,guarantee the quality

On-sale service:Choose suitable package and transportation,gurantee the goods reach to customers safely,save freight for customers

After-sale service:One-to-one VIP service

We solemn promise:

1) Contact with customers statedly

2) Guide the installation and using of products

3) Provide maintenance manual of related products

4) Provide mending material for products

FAQ

Q1: What’s the material of your products?

A: Our raw material is natural rubber, and rubber-dipped nylon cord fabric

Q2: Are you factory or trading company?

A: Qingdao Florescence Co.,Ltd is the company and factory,located in Jimo City,Qingdao,near to Qingdao port and Qingdao airport,which is convenient for transportation.

Q3: What’s your delivery time and payment terms?

A: Delivery time is according to customers’ size and order qty.The payment terms you could choose are T/T,L/C at sight,Western Union and so on.
