Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Specifications
Brand Name :
FLORESCENCE
Model Number :
NC4-5
Certification :
CCS,ABS,LR,BV,DNV
Place of Origin :
Shandong, China
MOQ :
1 piece
Price :
USD1000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100pcs per month
Delivery Time :
5-15 days
Packaging Details :
Pallet
Part :
marine airbag
Material :
Natural Rubber
Product name :
Ship launching marine air bag
Color :
Black
Application :
salvage,heavy lifting,Ship launching,Marine/quay/dock/boat,Ship Launching/landing/lifting
Size :
Customized Size
Diameter :
0.6-2.8m
Usage :
Ship launching,landing and slvage,Protect Boat,moving/lifting/landing /launching,Boat Fender
Standard :
ISO14409,ISO 14409
Packing :
Standard Package
Name :
marine equipment / marine part air bag supplier / marine airbag
Warranty period :
2 Years
Technology :
High Pressure,anti-explosion type. Whole-wrapping technology
Working pressure :
0.05MPa to 0.15Pa
Length :
5.0m-30m
Design using life :
6-10 years
Quality :
Top
Description

Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag

Florescence ship rubber airbag comply with ISO 14409. ship airbag can be used to launch and upgrade a ship up to 100,000DWT. Comparing to the traditional slipway launching method, the ship launching airbags are much environmental, because ship airbag can launch a ship at any seaside, so there's no need to worry about the construction of launching facilities; besides, the marine airbag need little maintenance and can be used repeatedly.

Marine salvage airbag is another application of ship launching airbags . Marine Salvage Airbags is the toughest air lifting bags. It can be used as salvage pontoon for the supporting docks, and other floating structures. Also can be used to salvage the shipwreck, rescue the floating bridge and dock construction. It really come into own when marine salvage airbags employed in heavy duty salvage work under severe environment.
Ship Launching Airbags
1. Material: Natural Rubber and Nylon Cord
2. Fittings: Inflation Valve, Pressure Gauge, Pulling Ring
3. Layers Range: 3-12 Layers
4. Size Range: Dia 0.6-2.8m, Len 5.0-25m
5. Service Life: 6-10Years
6. Certs: CCS, BV, ISO, RS, ABS, Etc
Structure of The Florescence ship launching airbags
Please the picture 1 of Florescence inflatable rubber airbag structure . It is composed by airbag body and terminal iron part. The airbag body is composed by natural rubber and strength fiber material through vulcanization processing; The terminal iron part is made of cast iron, it is combined closely with the bag body; One end is for pulling when move the airbag, and the other end is for charging and discharging the air. All the fittings in picture 2 and 3 will be supplied with airbags for free.
Advanges

●Different airbag size stock available, quick delivery

●Provide repair kit and on site instruction

●Long time service life can be reused many times

●Wear resistance and anti aging

●Good raw material and cord fabric

●Do no harm to the environment. Time & money saving

●Need no more than air compressors, winches and ropes

●Marine airbags are much cheaper and portable than other methods

Size Range:(airbag size depend on ship size)
Diameter(D) :
From 0.6m to 2.8m
Effective Length(EL) :
From 5.0m to 25.0m
Total Length(TL) :
From 7.0m to 28.0m
Standard Number of Layers:
Usually 4-10 layers
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Barge Float Balloon Heavy Moving Rubber Ship Launching Airbag
Overview
Florescence ship rubber airbag comply with ISO 14409. ship airbag can be used to launch and upgrade a ship up to 100,000DWT.
Comparing to the traditional slipway launching method, the ship launching airbags are much environmental, because ship airbag can
launch a ship at any seaside, so there's no need to worry about the construction of launching facilities; besides, the marine
airbag need little maintenance and can be used repeatedly.
Features
●Different airbag size stock available, quick delivery
●Provide repair kit and on site instruction
●Long time service life can be reused many times
●Wear resistance and anti aging
●Good raw material and cord fabric
●Do no harm to the environment. Time & money saving
●Need no more than air compressors, winches and ropes
●Marine airbags are much cheaper and portable than other methods
Application
1.For ship upgrading, conversion or new/repair launching (Ship launching airbags)
2.Marine airbag for salvaging sunken ship or heavy immersed steel structure
3.For hoisting and transporting heavy goods up to 10,000 tonnes structure on land
4.For floating use purpose as improve the draft.
5.Pneumatic rubber core for architecture engineering Container for storing and transporting gas and corrosive chemical liquid and pure water for voyage
6.Rubber bag for ship ballast
7.Rubber airbags used for culvert making

Our Culture

Company Mission:To promote the customers'sustainable growth to assist customers to become bigger and stronger,strive for contry's prosperity.
Vision:To become a leader in worldwide trading industry.
Values:Customer-orientd,mutual benefits,honesty,responsibility.
