Specifications
Brand Name :
BLM-IV-1
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
100KG
Price :
USD18-19/KG
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
300 Ton/Tons per Month
Delivery Time :
20-40 days
Packaging Details :
packed and labeled according to the regulations and customer's requests
Standard :
AISI, ASTM, BS, DIN, GB, JIS, Other,JIS,AISI,ASTM,GB,DIN,EN
Grade :
FeNi36
Thickness :
8mm-100mm
Type :
sheet,plate
Application :
as raw material produce OLED frame,machine,high temperature,oil,gas,oil well,corrosive environments
Delivery :
25-30 days subject to the clients' requirements and quantity
Price Term :
Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU
Description

Hot sale direct price invar 36 wire,invar 36 strip,invar material

1.Descriptions:

INVAR 36 is a nickel-iron, low-expansion alloy containing 36% nickel. It maintains nearly constant dimensions over the range of normal atmospheric temperatures, and has a low coefficient of expansion from cryogenic temperatures to about 500°F. The alloy also retains good strength and toughness at cryogenic temperatures.

INVAR 36 can be hot and cold formed and machined using processes similar to austenitic stainless steels. INVAR 36 is weldable using Filler Metal CF36 which is available in bare wire for both the GTAW and GMAW process.

Product Name Invar 36 Plate ASTM,ASTM GB
Type Invar Plate
Surface Treatment Black
Application petrochemical industry
Tooling and dies for composite forming
Cryogenic components
Laser components
Inventory INVAR 36 Plate, INVAR 36 Weld Wire
Features Low expansion rate up to 500°F
Readily weldable
Specifications AFNOR NF A54-301 (chemistry only), ASTM F 1684-06, EN 1.3912, UNS K93600, UNS K93603, Werkstoff 1.3912
Common Trade Names Nilo 36
Place of Origin Jiangsu, China (Mainland)
Delivery 25-30 days subject to the clients' requirements and quantity

2 . Specification:

GB/T UNS AISI/ASTM W.Nr
4J36 K93600 InVAR 36 1.3912

3 . Chemical Composition:

Grade ％ Ni Cr Fe C Mn Si Co Mo P S
Invar 36 Min 35 bal 0.2
Max 37 0.5 0.05 0.6 0.3 1 0.5 0.02 0.02

4 . Mechanical Properties:

Grade Tensile Strength Rm N/mm² Yield Strength Rp0.2 N/mm² Elongation A5 ％ Hardness
Invar 36 490 240 42 HB≤200

5 . Applications:

  • Advanced composite molds for aerospace industry
  • Bimetal thermostats
  • Clock balance wheels
  • Containers for LNG tankers
  • CRT applications: Shadow masks, deflection clips and electron gun components
  • Dimensionally stable instruments and optical devices
  • Echo boxes and filters for mobile telephones
  • Electrical circuit breakers
  • High voltage transmission lines
  • Magnetic shielding
  • Metrology devices
  • Pendulum clocks
  • Positioning devices
  • Precision condenser blades
  • Radar and microwave cavity resonators
  • Scientific instruments
  • Seals, spacers and specialized frames
  • Small electrical transformers
  • Special electronic housings
  • Temperature regulators
  • Transfer lines for LNG

6 . More pictures
