Three Layers PVC Plastic Sheet Extrusion Machine Bamboo Roofing Production.Extrusion Machine
Three Layers PVC Plastic Sheet Extrusion Machine Bamboo Roofing Production.Extrusion Machine
Three Layers PVC Plastic Sheet Extrusion Machine Bamboo Roofing Production.Extrusion Machine
Three Layers PVC Plastic Sheet Extrusion Machine Bamboo Roofing Production.Extrusion Machine
Specifications
Brand Name :
Xinkeda
Model Number :
LSJ-80/156+65/30
Certification :
ISO CE SGS GOST 9001
Place of Origin :
Qingdao of China
MOQ :
1set
Price :
FOB US $115,000/ Set
Payment Terms :
L/C, T/T
Supply Ability :
50set/year
Delivery Time :
60-80days
Packaging Details :
Wooden Cases and Wooden Pallet
Sheet Width :
720, 880, 1050mm
Sheet Thickness :
1-3mm
Calibrating Board :
Hydraulic Control
Transportation :
2 Sets of 40gp Containers
Quality Control :
Customers Come to Our Factory to Check
Main Electrical Components :
ABB, Omron, Rkc, Schneider, FUJI, Delix etc.
Description

pvc+pmma(asa) bamboo roofing sheet extruding line

PART 1: INTRODUCTION AND APPLICATION:
This pvc bamboo roofing sheet, is also named 3 layers composite tiles,synthetic resin tiles,bamsheets etc.This line consists of extruder, T-die,and accessory machines,like two rollers calendars, forming machine, cutting and ridge tiles forming machines. It can continuously extrude single layer pvc glazed tiles, PVC+PMMA,and PVC+ASA composite multi-layer glazed tiles. This glazed tiles
are widely used in pavilions, hotels, galleries, resorts, family building etc.

PART 2: SHEET SPECIFICATION:
1. Width: 720, 880, 1050mm
2. Thickness: 1-3mm
3. Can be co-exrtusion ABA, AB, ABC
4. ASA or PMMA co-extrusion

PART 3: PRODCUTION FLOWS:
High speed mixer--conical twin screw extruder--co-extruder--co-extrusion die head--embossing and cooling rollers--forming machine--saw cutting machine--stacker--pneumatic pressing machine for ridge tiles moulds

Extruder model SJSZ80/156 + SJ65/30
Capacity 350kg/h+50kg/h
Sheet specifications Width: 720/880/1040mm
Wave pitch:160mm
Wave length:220mm
Wave height:30mm
Thickness:1-3mm
Emboss rollers 1400mm*Φ300mm
T-die head JC-Times brand
Corrugation forming machine max haul off power 20KN
Haul off speed 0.3-5m/min
Cutting machine Pneumatic saw cutting
Stacker 6m
Ridge tiles forming machine With end cover, slope ridge for step roof, T ridge for step roof, top ridge for step roof
Other accessory machines High speed mixer, plastic crusher, plastic pulverizer etc


PART 4 PAYMENT, DELIVERY, AND OTHER SERVICE:
1. Payment: 40% for the prepayment by T/T, 60% for the downpayment by T/T or L/C available.
2. Delivery: 60 days after the prepayment, loading port: Qingdao, 2 sets of 40GP containers.
3. Warranty for machinery: 18months for mechanical parts, 12 months for electrical parts.
4. Installtion and commissioning
The seller will dispatch four 1-2 engineers from the seller to the buyer's factory for installation and commissioning and training till the buyer's workers can operate the machines independently.

Three Layers PVC Plastic Sheet Extrusion Machine Bamboo Roofing Production.Extrusion Machine

Best regards

Contact:Maggie

Whatsapp/Skype/Viber/Wechat: 0086 150 53256363

Email: Maggie@intermedios-cn.com
