High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
Specifications
Brand Name :
Xinkeda
Model Number :
LSJ-120/35
Certification :
ISO CE SGS GOST
Place of Origin :
Qingdao of China
MOQ :
1set
Price :
FOB US $95,000-295,000/ Set
Payment Terms :
L/C, T/T
Supply Ability :
50set/year
Delivery Time :
60-80days
Packaging Details :
Wooden Cases and Wooden Pallet
Condition :
New
Sheet Width :
600-800mm-1000mm
Sheet Thickness :
0.2-2mm
Sheet Application :
Thermoforming, Packing
Sheet Structure :
Single Layer, 2 Layers a/B, 3 Layers a/B/a
Max Capacity :
200-300kg/H-500kg/H
Die Head :
T-Type, Jc-Times Brand
Calibrating Method :
Three Roller Calendars
Main Electrical Parts :
ABB, Omron, Rkc, Schneider, Siemens
Guaranteed Time :
12 Months
Processing Material :
Pet, PP, PS
HS Code :
8477209000
Description


PP PS PET thermoforming sheet plate film extrusion line/making machine
This Plastic PP/PS/PET Sheet Production Line Maachineis specially designed for mono/multi Layer sheet for packing indrustry. The technology of "Single Screw extruding with low dew-point dehumidifying system " for high quality products in high transparency without buddle, which will be very important for thermoforming.

Raw Material:
1. can be virgin plastic material. PP, PS, PET
2. can be recyclable material, like PET Bottle Flakes, PP, PS granules
SHEET SPECIFICATION:
Usual Sheet Width: 600-800-1000mm
Usual Sheet Thickness: 0.2-2mm
High Speed PS Pet PP Sheet Extrusion Line , Plastic Sheet Making Machine
APPLICATION:
1. This line is specially used for producing PET/PBT/PP/PE/HIPS/EVAOH sheet.
2. Surface Treatment: Adding some additives can improve intensity/toughness/rigidity, flame retardant, embossing, frosting, etc.
3. Application: Packing, printing, stationery, art works etc.
4. Main Products: Gift/ad/file bag/lamp cover/food packaging

FEATURES:
1. Screw with special mixing and plasticization function.
2. Coat hanger T-type die head with two throttle design enable to regulate the sheet thickness accurately.
3. Horizontal. vertical, 45 degree incline type 3 Roller Calendars may be lifted freely, sheet thickness shall be regualted by screw and pressing roller.
4. Separate roller temperature control system to control the temperature of pressing roller to gain even sheet thickness.
5. Exact slicing machine, excellent cross surface.
6. Winder with big torque motor, and it's speed and tension force adjustable.
7. Automatic metering to set the length of the products.
MAIN TECHNICAL DATA:

PAR T1 THIS LINE CONSISTS OF (COMPULSORY)
1Automatic vacuum feeding machine1 set
2High efficiency single screw extruder (65/33, 75/33,90/33,120/33)1 set
3Hydraulic exchanging unit1 set
4Melting gear pump1 set
5T-type /hanger type die head (JC-Times brand)1 set
6Three Roller Calendars (alloy steel material )1 set
7Rollers thermoforming machine1 set
8Cooling frame and edge cutting unit1 set
9Haul off machine1 set
10Plastic cutting machine-guillotine1 set
11Twin position sheet winder1 set
12Stacker1 set
13Electrical cabinet (ABB,Omron, RKC,Schneider, Siemens etc)
14Spare parts1 set
PART 2 ACCESSORY MACHINE PARTS (OPTIONAL)
1Air compressor1 set
2Industrial water chiller1 set
PART 3 SHEET SPECIFICATIONS
1Sheet width600-800mm
2Sheet thickness0.2-2mm
3TypePet single layer/mono layer sheets
4Raw material1. Can be virgin plastic pet material
2. Can be recyclable material, like PET Bottle Flakes
PART 4 SHEET APPLICATIONS
1Packing, printing, stationery, art works etc.
2Main Products: Gift/ad/file bag/lamp cover/food packaging
PART 5 PAYMENT, DELIVERY AND AFTER SALE SERVICES
1Payment terms40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable
2Delivery time80 days after receipt of prepayment
3Packing methodWooden cases/pallets with stretching films
4Guaranteed time18 months for mechanical parts, 12 months for electrical parts
5After sale service

Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable
