UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
Specifications
Brand Name :
Xinkeda
Model Number :
LSJ-80/156+65/30
Certification :
ISO CE SGS GOST
Place of Origin :
Qingdao of China
MOQ :
1set
Price :
FOB US $105,000/ Set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50set/year
Delivery Time :
60-80days
Packaging Details :
Wooden Cases and Wooden Pallet
Name :
UPVC Corrugated Roofing Tiles Extruding Machine
Sheet Width :
720mm-1050mm
Sheet Thickness :
0.5mm-3mm
Sheet Applications :
Roofing Tiles/Sheets/Panels for Warehouses
Extruder Model :
Conical Twin Screw Extruder +Single Screw Extruder
Guaranteed Time :
12 Months
Description


UPVC/PVC corrugated/waved roofing tiles extruding line/machine
This corrugated roofing tiles extruding line is used to produce corrugated roofing tiles. This machine consists of: It includes a twin-screw extruder, a mould, a calibration unit, a haul-off unit, a cutter, a tilter and so on.
INTRODCUTION ANDAPPLICATION:
Corrugated roofing plate has an excellent corrosion resistance, weather resistance, easy processing, low cost
And many other characteristics and is widely used for roof material of workshops, warehouses.
Production line consists of:
1. Extruder: Single-screw extruder PP / PE / PC, conical twin-screw extruder PVC.
2. T die head: The hanger-type flow structure, a suitable compression ratio to ensure the stability of material flow evenly.
3. Calibrating molds: Rational design, the unique design of the cooling flow to ensure the accuracy of products,
4. Hauling machine: Roller traction, using high quality NBR rubber roller, pneumatic adjustment, and frequency speed adjustment.
5. Cutting Machine: Knife cutting, fast, good accuracy.
MACHINE SPECIFICATIONS


PAR T1 THIS LINE CONSISTS OF (COMPULSORY)

1
Automatic spring feeding machine
1 set

2
Conical twin screw extruder SJSZ-80/156
1 set

3
Single screw extruder SJ-45/30 or 65/30 for UV extrusion
1 set

4
T-type /hanger type die head (JC-Times brand)
1 set

5
Corrugation forming boards
1 set

6
Cooling frame and edge cutting unit
1 set

7
Haul off machine
1 set

8
Plastic cutting machine-guillotine with meter counting
1 set

9
Stacker
1 set

10
Electrical cabinet (ABB, Omron, RKC, Schneider, Siemens etc)

11
Spare parts
1 set

PART 2 ACCESSORY MACHINE PARTS (OPTIONAL)

1
High speed hot and cold mixer SRL-Z 300/600
1 set

2
Plastic crusher SWP-450
1 set

3
Plastic pulverizer SMP-400
1 set

4
Air compressor
1 set

5
Industrial water chiller
1 set

PART 3 SHEET APPLICATIONS

1
Roof panels, roof tiles, roof sheets, ceilings

2
Factories, warehouses, farm building, greenhouses, canopies, walkways, patio covers,
Pergolas, cladding

PART 4 PAYMENT, DELIVERY AND AFTER SALE SERVICES

1
Payment terms
40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable

2
Delivery time
70 days after receipt of prepayment

3
Packing method
Wooden cases/pallets with stretching films

4
Guaranteed time
18 months for mechanical parts, 12 months for electrical parts

5
After sale service
Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable

6
Contact
Ms Helen Gao (mob: 0086-15192039505)

Sheet specifications

Sheet width
720, 760, 820, 840, 860, 880, 900, 930, 950, 980, 1050mm etc

Sheet thickness
0.5, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5, 3.0mm

Sheet length
4m, 6m or customized

Sheet weight
1mm thickness 1.4kg-1.85kg/m2, 2.0-2.4 thickness 2.5-3kg/m2

Suitable environment
-40(50)ºC-70ºC

Surface treatment
With UV coating

Service life
More than 25 years, 10years can be guaranteed

Colors and tints
Clear, bronze, opal

Textures
Can be textures


UPVC / PVC Single Screw Plastic Extruder Corrugated / Waved Roofing Sheets Machine
