2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
Specifications
Brand Name :
Xinkeda
Model Number :
LSJ-130/36+45/30
Certification :
ISO CE SGS GOST
Place of Origin :
Qingdao of China
MOQ :
1set
Price :
FOB US $253,000/ Set
Payment Terms :
L/C, T/T
Supply Ability :
50set/year
Delivery Time :
60-80days
Packaging Details :
Wooden Cases and Wooden Pallet
Sheet Width :
2100mm
Sheet Thickness :
1-10mm
Die Head :
T-Type, Coat Hunger Type
Processing Technology :
Three Roller Calendars
Installed Power :
500kw
Machine Dimenison :
30m*4.5m*3.5m
Description

Solid polycarbonate transparent/clear roofing sheet machine
PART 1 Introduction
This machine is specially used to produce the polycarbonate universal solid sheets, which is as clear as glass, but the density of PC is only half of glass. And the PC solid sheet is with high impact resistance, which is also called " Unbreakable glass" . By changing the three rollers calendars, this line can also produce frosted solid sheets, diffusion solid sheets, embossed solid sheets and anti-scratch solid sheet etc for different applications.

PART 2 Solid Sheet Specifications:
1) Thickness: 1.8mm-16mm
2) Width range: <= 2,100mm
3) Length: Any dimension.
4) Color: Clear, blue, green, opal, brown, blue green etc.

PART 3 Solid Sheet Application:
PC solid sheet is easy to be shaped with cold bending, equipment and heat synthesis processing accordingly, which used widely in all kinds of architecture, engineering and decoration etc.
1) Lighting Roofing
2) Advertisement light box
3) Carport and awnings.
4) Sound barrier
5) Protective & Police device
6) Indoor partition
7) Indoor ceiling etc

PART 4 Polycarbonate solid sheet extrusion machine specification:

THIS MACHINE MAINLY CONSISTS OF:
1MD-500 Drying and mixing machine1 set
2XAL-3HP Automatic vacuum feeding machine1 set
3SJ-130/36 Single screw extruder for PC1 set
4Hydraulic screen exchanger for PC1 set
5Melting gear pump for PC1 set
6SJ-45/30 Single screw co-extruder for UV layer on both sides1 set
7Melting gear pump for UV1 set
8T-type die head(2300mm width)1 set
9Three-roller calendars with 45 degree angle installation1 set
10Rollers thermo-controlling machine1 set
11Protective film coating unit1 set
12Cooling frame & edge cutting device1 set
13Haul-off machine with double rollers1 set
14Saw cutting machine1 set
15Belts conveying table1 set
16Sheet stacker1 set
17Electrical cabinet1 set
18Spare parts1 set


2100mm Plastic Sheet Extrusion Machine For Solid Polycarbonate Transparent / Clear Roofing Sheet
