Specifications
Brand Name :
MAZS
Model Number :
MAΦ400 × 800
Certification :
CE,ISO
Place of Origin :
MADE IN CHINA
MOQ :
1set
Price :
USD
Payment Terms :
T/T or 100% at sight LC or 30% deposit and 70% before shipping.
Supply Ability :
50sets per year
Delivery Time :
150-180 working days
Packaging Details :
Machine will be fixed inside container by steel wire(Export standard sea package)
Description of goods :
Cold Rolling Mill
Material :
carbon steel
Input thickness (mm) :
≤20
Output thickness (mm) :
≥0.5
Strip (mm) :
≤600
Rolling pressure (T) :
160
Color :
As our standard or order by user
Voltage :
380V 50Hz 3phases or order by the user
Description

1. Description of goods:

Steel cold Rolling mill equipped with heavy duty reduction gear hydraulic expansion cylinder for Coiler.

2. Features:
1. The 2-Hi cold rolling mill is a kind of portable type.
2. One stand and two frames are made from fabricated steel plates.
3. The number 2 Rolls on this cold rolling mill are made of chilled material.
4. It is equipped with heavy duty reduction gear.
5. The screw down system is manual.
6. We adopt one number C.I. casting flywheels.


3. Rolling Conditions:
Material: carbon steel
Input width: ≤150mm, thickness: 2.75mm
Output width: ≤150mm, thickness≥: 0.8mm
Rolling force: p＝60t
Rolling speed: v≤13m/min

4. Parameters of Ф165×250 Two High Cold Rolling Mill:
Rolling mill: Ф165×250 two roller mill
Electric screw-down motor: 2.2kw×2
It can be pressed down or lifted at the same time, and pressed down or lifted separately.
Worm gear box: HT200
Main motor: YZ type, 30kw-6
Main reducer: JZQ650
Coiler: It adopts hydraulic expansion cylinder.
Reducer: JZQ350
Motor: YLJ180-160-6

5. Technical Parameters of 2-Hi Cold Rolling Mill:

Type Φ120 × 160 Φ150 × 220 Φ175 × 400 Φ250 × 500 Φ320 × 600 Φ400 × 800 Φ500 × 1000
Input thickness (mm) ≤4 ≤4 ≤4 ≤8 ≤10 ≤20 ≤30
Output thickness (mm) 0.15 ≥0.35 ≥0.35 ≥0.4 ≥0.4 ≥0.5 ≥0.6
Strip (mm) 10-100 ≤150 300 370 450 ≤600 800
Rolling pressure (T) 65 100 100 120 150 160 260
Rolling speed (m/min) 12 13 13 13 13-15 13-15 15-25
Main motor (KW) 22 30 37 55 75 155 160
Press-down motor (KW) 1.5 2.2 2.2 3 4 4 7.5
Press-down speed (mm/s) 0.09 0.09 0.09 0.09 0.09 0.12 0.12
Speed reducer JZQ550 JZQ750 JZQ750 JZQ750 JZQ1000 JZQ115 JZQ130
Weight (T) 4.8 5.8 7 12.8 19 40 50
