Municipal 1040mm Hollow Fiber MBR
Municipal 1040mm Hollow Fiber MBR
Municipal 1040mm Hollow Fiber MBR
Municipal 1040mm Hollow Fiber MBR
Specifications
Brand Name :
CNKHONG
Model Number :
KH-MBR-18-Co-PVDF
Place of Origin :
China
MOQ :
100M2
Price :
USD14/M2
Payment Terms :
L/C, T/T
Supply Ability :
1200M2/day
Delivery Time :
within 10 days
Packaging Details :
Carton box or Pallet
Material :
Reinforced PVDF
OD/ID :
2.2/1.0mm
Size :
1810x1250x47mm
Flux Rate :
15-20LMH
Transmembrane Pressure :
-0.08MPa
Temperature Scope :
1-40C
Description

Municipal Wastewater Biochemical Treatment MBR Membrane with PVDF 0.05 pore size

1.Introduction

Membrance Bio-Reactor,MBR), Is a membrane separation unit is introduced into traditional sewage biological

treatment technology of the new processing technology, membrane separation unit can replace the traditional

two precipitation pool functions at the same time, with further removal of organic matter and nitrogen and

phosphorus, is currently the most advanced and efficient water treatment technology.JHM - MBR is lined with

enhanced hollow fiber membrane based on the development of high-end MBR membrane module .

2.Advantages

Membrane high mechanical strength, stable water quality, operation flux is big, long service life

1).JHM MBR membrane is high efficiency, especially capable in frequent disuse occasions.

2).Anti-oxidant modification on the in-let membrane surface makes it more durable in harsh environment like

wastewater.

3).Fine inner diameter of the membrane fiber can ensure that sludge blocks the membrane pore the instant

the fiber is broken accidentally, endowing the membrane with self-repairing function without affecting outflow

water quality.

4). A longer shelf life than other manufacturers

3.Technical Parameters

Item/Model KH-MBR-25-CO-PVDF KH-MBR-30-CO-PVDF KH-MBR-35-CO-PVDF
Membrane Area(M2) 25 30 35
Height 1560 mm 1810 mm 1810 mm
Width 1040 mm 1040 mm 1250 mm
Thickness 47 mm 47mm 35 mm
Dry Weight 20 kgs 25 kgs 30 kgs
Membrane material Reinforced PVDF Reinforced PVDF Reinforced PVDF
Micro pore size 0.05μm 0.05μm 0.05μm
ID/OD of Membrane 0.9/2.2mm 0.9/2.2mm 0.9/2.2mm
Suspend solid <5mg/L <5mg/L <5mg/L
Temperature 5-40℃ 5-40℃ 5-40℃
PH range 2~11 2~11 2~11
Flux for waste water 15~20 LMH 15~20 LMH 15~20 LMH
Operating Method Sucking out 8 mins and staying 2 mins Sucking out 8 mins and staying 2 mins

Sucking out 8 mins

and staying 2 mins
Cleaning Chemicals 500-3000ppm Sodium Hypochlorite

500-3000ppm

Sodium Hypochlorite

500-3000ppm

Sodium hypochlorite

Municipal 1040mm Hollow Fiber MBR

Municipal 1040mm Hollow Fiber MBR
