Main Features

◆Support 4CH AHD Camera input;

◆VGA output for optional;

◆.Exclusive pre-allocated file system, solve the file fragmentation / SD lost / file garbled etc issue,protect data file;

◆8-36V Wide Voltage, Lower power consumption;

◆SD Card Storage ( Dual SD Card, each max 256GB ),

◆Support 4CH alarm input, 1CH independent alarm output;

◆Optional single RS232 serial port or single RS485 extension

◆Support GPS/BD/G-sensor module extension

◆Realize realtime monitor through 3G/4G;

◆Support WIFI module, can download data automatically

◆Support SMS romote configure/ control device;

◆Support Broadcast/Intercom/Text sent etc;can add oil sensor/temperature sensor/POS/LED Advertisement Panel;

◆High vibration Aviation plug

Product Details

◆Support 4CH 1080P million pixels HD video recording.support 4CH 1080P million pixels AHD input/ 4CH analog SD camera input;

◆ VGA output for optional ;

◆ High quality real time recording, 1080P720P/CIF/HD1/D1 Optional, quality adjustable;

◆ Professional Car Power Design,8-36V wide voltage,Provide reverse voltage/overload/short circuit protection, to meet kinds of car application;

◆ Support 12VDC/2.5Amp output voltage,power supply for Camera/Screen etc;

◆ Dual SD Card Support, each max 256GB,,protect DVR from shock & Dust damage;

◆Watchdog abnormal restart function,protect SD Card and Record;

◆ Exclusive File System protect data completeness,prevent SD Card fragment;

◆ ACC Delay off,can set 24 hours;

◆ Auto Record/Manual Record/Alarm Record etc working mode to meet different requirements;

◆ Show Car status/Plate/Driving Route/Low Speed/Over Speed information for convenient management;

◆ Support GPS/BD G-sensor Optional;

◆ Optional single RS232 serial port or single RS485 extension

◆ 4CH Alarm input(Door Open,Light,Turn direction,brake,reverse etc),can linkage kinds of alarm;

◆ 1CH Alarm Output;

◆ Support picture snap when alarm;

◆ Easily Smart GUI Interface, saving time in device setting;

◆ Can upgrade the software via SD card.

◆ Stability Aviation plug, easily connecting and high shock proof;

◆ Be Customized according your request;
