Medical Laboratory Automatic Microcomputer Controlled Pressure Steam Sterilizing Machine dental Autoclave
Medical Laboratory Automatic Microcomputer Controlled Pressure Steam Sterilizing Machine dental Autoclave
Specifications
Brand Name :
Mdbes
Model Number :
M-AB16
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1PC
Price :
980USD
Payment Terms :
Western Union
Delivery Time :
5 DAYS
Packaging Details :
Standard package
Sterilization Class :
B
Capacity :
16L
Inner Chamber Size :
230mm X 360mm
Aotoclave Size :
440mm(W)*400mm(H)*620mm(D)
Capacity of Water Tank :
Approx 2.5 L
Operation Temperature :
5-40 Degree
Net Weight :
42 KGS
Noise Level :
Less Than 70dB
Nominal Power :
1750va
Relative Humidity :
Max 80%, Non Condensing
Description

Class B Dental Used Steam Sterilizers
Medical Laboratory Automatic Microcomputer Controlled Pressure Steam Sterilizing Machine dental Autoclave

Thank you for choosing the our steam sterilizers.
Prior to operating this instrument, please read the operations manual carefully and follow all installation instructions.

Need Maintenance
If E88 appears on the screen when power on or appears on the report, please call your dealer or local service maintenance. Your steam sterilizer need a regular maintenance.

1. General

The sterilizer described in this manual is intended for the sterilization for medical, dental, beauty, Vet and Tattoo fields. It operates automatically with 134°C and 121°C sterilization temperatures. This sterilizer is in compliance with the European Directive 93/42/CEE and it has been produced in accordance with the EN 13060.

2. Technical specifications

Item Parameter
Chamber Φ 230mm x 360mm
Rated Voltage AC 220-240V 50Hz (110-130V 60Hz)
Circuit breaker F16A/400V (F20A/400V for 120V)
Nominal power 1750VA
Sterilization 121°C /134°C
Capacity of the distilled water tank Approx 2.5 L (Water at level Max)
Approx 0.5 L (Water at level Min)
Operation temperature 5°C-40°C
Exterior dimensions 440mm(W)*400mm(H)*620mm(D)
Net weight 42kg
Noise level <70 dB
Relative Humidity Max 80%, non condensing
Atmospheric pressure 76 k/Pa - 106 k/Pa

3. Packing content

No. Item Quantity
1 Steam sterilizer 1
2 Instrument tray 2
3 Instrument tray rack 1
4 Instrument tray handle 1
5 Door adjustment tool 1
6 Draining hose 2
7 Instruction manual 1
8 Door seal 1



4. Installation

  • Ensure that the sterilizer is installed with 10cm ventilation space on all sides of the sterilizer, and 20cm on top side. The clearance required to open the door is 40cm.
  • The sterilizer should be placed on a level worktable.
  • Do not cover or block the door, ventilation or radiation openings on the sterilizer.
  • Do not install the sterilizer near a sink or in a location where it is likely to be splashed.
  • Do not install the sterilizer nearby a heat source.

5. Operation

5.1 Setup

5.1.1 Open the door and remove all of the inner contents for unpacking.
5.1.2 Connect the power cord to an outlet of the appropriate voltage.
5.1.3 Power on
The switch is located underneath the control panel on the front side of the machine.
After switching on, the machine turns on the LCD and shows the door position,
water level, working program, date, time and etc.

7. Maintenance

Frequency Maintenance operation
Daily Clean the door seal
Clean the external surface
Weekly Clean the distilled water tank
Clean the sterilization chamber
Every month(depending on the use) Clean the filter inside the chamber and tank
Every 3/6 Months (depending on the use) Replace the bacteriological filter
Every year Replace the door seal

7.1 Clean the distilled water tank every week with isopropyl alcohol or a medical disinfectant.

7.2 Clean the chamber weekly.

7.2.1 Remove all trays and the tray rack from the chamber.

7.2.2 Clean the chamber with a smooth cloth saturated with distilled water.

7.2.3 Apply the same procedure for the trays and rack.

7.3 Replacement of the bacteriological filter.

7.3.1 The bacteriological filter is in the back of the sterilizer.

7.3.2 Unscrew the filter by hand anti-clockwise.

7.3.3 Place the new bacteriological filter.

7.3.4 Screw the new filter by hand clockwise.

7.4 Clean the door seal.

Clean the door seal weekly, with a smooth cloth saturated with the distilled water.
