Specifications
Place of Origin :
China
Brand Name :
Fiberroad
MOQ :
1pc
Packaging Details :
Standard neutral or brand packing
Delivery Time :
2-3 workdays
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
5000pcs/Month
Model Number :
FR-MC26C-XXXX
Certification :
ISO9001, CE, FCC, ROHS
Product name :
Fiber Optic Media Converter
Mode: :
Single mode , Multi mode
Data rate: :
10/100/1000Mbps
Data Rate FX/TX: :
100Base-TX or 1000Base-T,1000Base-SX/LX
Flow Control: :
Full Duplex ,Half duplex
Wavelength: :
850nm/1310nm/1550nm
Price :
Pls send request details
Description

Network SFP Fiber Optic Media Converter With LFP Dual Power Supply 220VAC

Internal power supply media converter can interconvert electrical signals of 10/100/1000Base-Tx To 1000Base–FX twisted pairs with optical signals of 1000Base-FX. It extends the network transmission distance from 100m via copper cables to 100 km via fiber optical cable.

Features:

  • 10/100/1000Mbps auto-sensed, facilitating network upgrade
  • Built-in efficient switching core to implement flow control and reduce broadcast packets
  • Full-duplex and half-duplex auto-sensed
  • Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation
  • Supporting half /full-duplex of FX.
  • DIP switch to set different configurations (LFP)
  • Supporting low-time lag transmission
  • Extremely low power consumption (less than 3W), reliable and stable performance
  • Options in single mode dual fiber or Multi-mode dual fiber.

Technical Paramete Description:

Parameter

Specifications

Access mode

10/100/1000Mbps

Standard

IEEE802.3, IEEE802.3u,IEEE802.3Z IEEE802.3x ,1000Base-FX

Wavelength

850nm/1310nm/1550nm

Transmission distance

Multi-mode: 2 km;

single mode: 20/40/60/80/100/120 km;

Cat-5 twisted pairs: 100m

Conversion means

Store and Forward mode or Cut-Through mode

Flow control

Full duplex: flow control;

Half duplex: back pressure

Input voltage

DC 5V

Power consume

<3W

Operating temperature

0~50ºC

Operating humidity

5%~90%

Maintaining temperature

-40~70ºC

Maintaining humidity

5% ~ 90% non-condensing

Dimensions

156mm (W)×128mm(D)×32 mm(H) (standalone )

112.8mm (W)×77.2mm(D)×23 mm(H) (plug-in modular

Order Informations

P/N

Description

-

X

X

X

X

FR-MC26C-XXXX

10/100/1000Base-TX to 1000Base-FX Media Converter Card

S: Duplex Single-mode

M: Duplex Multi-mode

B: Simplex Single-mode

SFP: SFP Slot

3: TX 1310nm

4: TX 1490nm

5: TX 1550nm

8: TX 850nm

S: SC

F: FC

T: ST

L: LC

05: 550M

2: 2KM

20: 20KM

40: 40KM

FR-MC26U-XXXX

10/100/1000Base-TX to 1000Base-FX Media Converter (Standalone)
