Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX
Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX
Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX
Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
Fiberroad
Certification :
CE
Model Number :
FR-CXXM/DXX
MOQ :
1Set
Price :
Pls send request details
Packaging Details :
Standard neutral or brand packing
Delivery Time :
2-3 workdays
Payment Terms :
100% t/t in advance
Supply Ability :
5000pcs/Month
Name :
rack mount media converter
Channel :
4 / 8 / 16 Channel
Type :
Mux/ Demux
Wavelength :
1270~1610nm
Channel Ripple :
0.3dB
Channel Space: :
20nm
Description

Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX

Parameter

4 Channel

8 Channel

16 Channel

Mux

Demux

Mux

Demux

Mux

Demux

Channel Wavelength (nm)

1270~1610

Center wavelength Accuracy (nm)

±0.5

Channel Spacing (nm)

20

Channel Passband (@-0.5dB bandwidth (nm)

>13

Insertion Loss (dB)

≤1.6

≤2.5

≤4.5

Channel Uniformity (dB)

≤0.6

≤1.0

≤1.5

Channel Ripple (dB)

0.3

Isolation (dB)

Adjacent

N/A

>30

N/A

>30

N/A

>30

Non-adjacent

N/A

>40

N/A

>40

N/A

>40

Inertion Loss Temperature Sensitivity (dB/℃)

<0.005

Wavelength Temperature Shifting (nm/℃)

<0.002

Polarization Dependent Loss (dB)

<0.1

Polarization Mode Dispersion

<0.1

Directivity (dB)

>50

Return Loss (dB)

>45

Maximum Power Handling (mW)

300

Opterating Temperature (℃)

-5~+75

Storage Temperature (℃)

-40~85

Package dimension (mm)

L100 x W80 x H10

L141 x W115 x H18

Specification may change without notice.

Above specification are for device without connector.

Rack Mount 10G Media Converter , 4 / 8 / 16 Channel CWDM MUX
