Functional Converter Card 2x1.25G1000 Base-X to 1x2.5G 1000 Base-X Multiplexer
Functional Converter Card 2x1.25G1000 Base-X to 1x2.5G 1000 Base-X Multiplexer
Specifications
Brand Name :
Fiberroad
Model Number :
FR-6301
Certification :
CE FCC RoHS
Place of Origin :
China
MOQ :
1PC
Price :
Pls send request details
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs/Month
Delivery Time :
2-3 workdays
Packaging Details :
Standard neutral or brand packing
Product name :
managed media converter
Warranty :
life-long maintance
Operating temperature :
0 ~ +50℃
Transmission distance :
2/25/40/60/80/100/120km
Material :
metal,Iron
Storage temperature :
-20 ~ +70℃
Description

Functional Converter Card 2x1.25G1000Base-X to 1x2.5G 1000Base-X Multiplexer

The Gigabit Ethernet Multiplexer aggregates 2 port Gigabit Ethernet into 1 port 2.5G uplink, reducing the conversion CAPEX and increasing the fiber utilization effectively. The multiplexer can be used either in point-to-point topology fuctioning as a media converter for transporting two Gigabit Ethernet services over one fiber or in CWDM system working as a wavelength converter for extending the system’s transmits- sion capacity doubly. The multiplexer is equipped with three SFP-based ports: SFP1 is 2.5G uplink port, SFP2 and SFP3 are Gigabit Ethernet service ports.The multiplexer must be used in couples.

Specification

Transmission Distance

Twisted-pa: 100M (standard CAT5/CAT5e cable)
SFP, Distance depend on plug-in Fiber Tranceiver
Forwarding Mode Store-and-forward
Forwarding Frame Length 9000Bytes
Function Features

Provide 3 standard SFP slots:

2 x GE ports at the client side

1 x 2.5G ports at the line side;
2 x GE ports at the client side are isolated from each other;


Support cross mapping of the data of all ports;
Support statistics on error packet of each port;
Support loopback setting of the client side and the line side;
Support SNMP network management.
Power Requirement Operating Voltage DC 5V
Rated Current: 1A
Power Consumption: Full-load<4W
Environmental
Requirement		 Operating Temperature: 0℃~50℃
Storage Temperature : -10℃~ 55℃
Relative Humidity: 5%~95%
MTBF: 56,000 h
Enclosure: Metal
Dimensions 120mm(H)×90mm(D)× 22mm(W)
Weight 100g
Warranty 1 Year
Emissions FCC Class A, CE Class A

Dimensions

Functional Converter Card 2x1.25G1000 Base-X to 1x2.5G 1000 Base-X Multiplexer
