DCM Dispersion Compensation Device
DCM Dispersion Compensation Device
Specifications
Brand Name :
FiberRoad
Certification :
FCC Class A, CE Class A
Place of Origin :
China
MOQ :
1pc
Price :
Pls send request details
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
5000pcs/Month
Delivery Time :
2-3 workdays
Packaging Details :
Standard neutral or brand packing
Product name :
DCM Dispersion Compensation Device
Dimensions :
482.6(W)x350(D)x43.6(H)(mm)
Input voltage :
NA
Operating temperature :
0~60ºC
Description

DCM Dispersion Compensation Device

Fiberroad's Dispersion Compensation Module Device is with slope dispersion compensation for standard single-mode fiber can DCM (G.652) were dispersion and dispersion slope compensation broad band in the C-band, allowing the system to optimize residual dispersion. In the dispersion compensation value of 1545nm wavelength dispersion can reach -2070ps / nm.

The DCMs offer a high dispersion compensation level and a very low insertion loss penalty. They provide negative dispersion compensation over the full C-Band with possible distance extensions of up to 120 kilometers.

Features

- DWDM system dispersion compensation and broadband low residual dispersion
- G.652 fiber C-band 100% slope compensation (standard value)
- Low insertion loss
- Low polarization mode dispersion
- Performance indicators by
- Telcordia GR-2854-CORE standard certification
- Reliability by Telcordia GR-1221-CORE standard certification

Specifications

Parameter DCM-20 DCM-40 DCM-60 DCM-80 DCM-100 DCM-120
Compensated Distance (km) 20 40 60 80 100 120
1545nm dispersion (ps/nm) -340+/-10 -670+/-20 -1000+/-30 -1340+/-40 -1680+/-50 -2010+/-60
1545nm relative dispersion slope (nm-1) 0.0036 +/- 10%
Insertion Loss (dB) ≤3.3 ≤4.7 ≤6.4 ≤8.0 ≤9.5 ≤11.0
Insertion Loss (typ) (dB) 2.7 4.0 5.4 6.7 8.0 9.3
Polarization mode dispersion (ps) ≤0.6 ≤0.7 ≤0.8 ≤0.9 ≤1.0 ≤1.1
Polarization mode dispersion (typ) (ps) 0.2 0.3 0.4 0.5 0.6 0.7
Polarization dependent loss (dB) ≤0.1 ≤0.1 ≤0.1 ≤0.1 ≤0.1 ≤0.1

Parameter MIN MAX
Brillouin scattering threshold (dBm) 6 -
Non-linear coefficient (n2/Aeff) (W-1) - 1.4*10-9
Effective area (Aeff)@1550nm (um2) 20 -
Maximum input power (dBm) 23
Operating temperature range -5℃ 70℃
Storage temperature range -40℃ 85℃
Relative humidity <85%
Environmental / reliability testing Comply with Telcordia GR-2854 and GR-1221 standard
Size 482.6(W)x350(D)x43.6(H)(mm)
