125M - 2.5G Optical Electrical Optical Converter Network Management 1R
125M - 2.5G Optical Electrical Optical Converter Network Management 1R
125M - 2.5G Optical Electrical Optical Converter Network Management 1R
125M - 2.5G Optical Electrical Optical Converter Network Management 1R
125M - 2.5G Optical Electrical Optical Converter Network Management 1R
125M - 2.5G Optical Electrical Optical Converter Network Management 1R
Specifications
Brand Name :
fiberroad
Certification :
CE
Place of Origin :
ShenZhen China
MOQ :
1PCS
Price :
Pls send request details
Payment Terms :
T/T
Delivery Time :
2-3 workdays
Packaging Details :
Standard neutral or brand packing
Supply Ability :
5000pcs/Month
Interface Type :
SFP to/from SFP
Transmission Distance :
Up to SFP module （ Max 80Km ）
Operating Temp :
0 ～ 50 ℃
Storage Temp :
-10 ～ 70 ℃
Humidity :
5%~90% （ non-condensing ）
Standalone :
156mm （ W ）× 128mm （ D ）× 32mm （ H ）
Description

125M - 2.5G Optical Electrical Optical Converter network management 1R

Electrical Optical Converter Application:

Fast Ethernet, STS-3/STM-1, ESCON/SBCON,
STS-12/STM-4, 1×Fiber Channel, Gigabit Ethernet,
2×Fiber Channel, STS-48/STM-16, 2.5 InfiniBand,

Electrical Optical Converter Features:


 Support 2U Rack(16 Slots )and independent use
 support network management(Web SNMP, Console),
 Support in-band management
 support ITUT prescribed DWDM/CWDM wavelength
 transmission rate:125Mbps~2.5Gbps
 Support Jumbo Frame
 Transparent Transport and very low delay
 support DMI function for SFP fiber module
 support hot plugging
 Full State Led display

Electrical Optical Converter Technical Information:

Performance Data Technical Indexes

Access Type / Transmission Speed

 Fast Ethernet 125Mbps
STS-3/STM-1 155.52Mbps
ESCON/SBCON 200Mbps
STS-12/STM-4 622.08Mbps
1×Fiber Channel 1.0625Gbps
Gigabit Ethernet 1.25Gbps
2×Fiber Channel 2.125Gbps
STS-48/STM-16 2.48832Gbps
2.5 InfiniBand or PCI Express 2.5Gbps
Interface Type SFP to/from SFP
Transmission Distance Up to SFP module ( Max 80Km )
Local SFP Support SFP/CWDM/DWDM,Specific optical parameters please refer different modules's parameters
Remote SFP Support SFP/CWDM/DWDM,Specific optical parameters please refer different modules's parameters
power requirement

Rack-mountable : AC 85 ～ 220V OR

DC -48V dual-supply,optional

Standalone: AC 220V OR -48V

Power consumption: ≤ 3W
Work environment

Operating Temp: 0 ～ 50 ℃

Storage Temp: -10 ～ 70 ℃

Humidity: 5%~90% ( non-condensing )
Dimension

Card : 11.5mm ( W )× 78mm ( D )

Standalone : 156mm ( W )× 128mm ( D )× 32mm ( H )
