Mini SFP Fiber Optic Media Converter , single mode Sfp media converter
Mini SFP Fiber Optic Media Converter , single mode Sfp media converter
Specifications
Place of Origin :
SHENZHEN
Brand Name :
FIBERROAD
Certification :
CE, FCC, Rohs
Model Number :
FR200-201-SFP
MOQ :
1Pcs
Price :
Pls send request details
Packaging Details :
Standard neutral or brand packing
Delivery Time :
2-3 workdays
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs/Month
Description

Mini SFP Fiber Optic Media Converter , single mode Sfp media converter

•Key Features
•- 10/100Base-TX UTP to 100Base-FX Mini SFP Fiber Optic media convertion
•- Support IEEE802.3 10Base-T,
•IEEE802.3u 100Base-TX/FX standards
•- Choice of SC, BiDi or other connectors for
•multimode and single-mode
•- DIP switch to set different configurations
•- LFP (Link Fault Pass-through) support
•- Compact package size

The mini 10/100Base-TX to 100Base-FX Mini SFP Fiber Optic Media Converter is fully compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX protocols. The converter can support auto MDI-MDIX function, flow control for full and half duplex operation, link fault pass through function (LFP), etc.

A DIP switch is placed at the bottom of the case. Depend on different configurations, the user can set the different operating mode (UTP port speed 10M or100M, full or half duplex mode, pass through mode, LFP enable or disable).

Technical Specifications:

Data Rates:

- 10/100 Mbps (802.3 10Base-T/802.3u 100Base-T)

- 100Mbps (100Base-FX)

Input Power Requirements:

- Input voltage ............................................ DC 5-12V

………….or AC 6-12V 50/60Hz (optional)

- Power consume ............................ 3 Watts maximum

Environmental Conditions:

- Operating temperature ....................... …0℃ to 40℃

- Cooling ........................................ free air convection

- Storage temperature ...................... -20℃ to +85℃

- Operating Humidity …... 90% max, non-condensing

Mechanical Specifications:

- Case Material……………....…………………..Iron

- Case Color…………………………………….Black

- Net Weight…………..………….150g approx. / unit

- Dimensions………..60 (W) x 20 (H) x 90 (L) (mm)

Do not include transceiver length

Warranty : 2 year hardware warranty

*Specifications subject to change without notice.
